Sel 2414 - MAP Command (Display DNP3 Maps)

7.17
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Communications
ASCII Commands
MAP Command
(Display DNP3 Maps)
The MAP command is only available if DNP3 has been selected as the protocol
on a serial or Ethernet port. The MAP command accesses the port DNP3 settings
and is similar to the SHOW DNP command. However, unlike the SHOW DNP
command, the MAP command displays DNP3 information by port number. You
can issue the MAP command with the port parameter (from 1 to 4) to view the
DNP3 settings for that port number. If you specify port number 1, you must also
include the session number (from 1 to 3) to display.
To observe Port 1 DNP3 maps and settings for session 1, type MAP 1 1
<Enter>. You will see a screen with the format shown in Figure 7.4.
Tab le 7.33 M AP Co mma n d
Command Description Access Level
MAP port Show the serial DNP3 settings for port port (similar to
SHOW DN).
1, 2
MAP 1 session Show the DNP3 settings for Ethernet Port 1 and
session session (similar to SHOW DN).
1, 2
=>MAP 1 1 <Enter>
SEL-2414 Date: 11/04/2005 Time: 10:36:46
DEVICE
Map 1
Transport TCP
Device IP Address 192.168.0.3
Master IP Address 192.168.0.13
Device DNP TCP and UDP Port 20000
Device DNP Address 15
Master DNP Address 0
Binary Inputs
--------------------------------------------------------------------------------
INDEX POINT LABEL EVENT CLASS SER TIMESTAMP
0 ENABLED 1 No
1 T01_LED 1 No
2 T02_LED 1 No
3 T03_LED 1 No
…
97 SET13 1 No
98 SET14 1 No
99 SET15 1 No
Binary Outputs
--------------------------------------------------------------------------------
INDEX POINT LABEL
0 RB01
1 RB02
2 RB03
…
29 RB30
30 RB31
31 RB32
Counters
--------------------------------------------------------------------------------
INDEX POINT LABEL EVENT CLASS DEADBAND
0 SC01 0 1
1 SC02 0 1
2 SC03 0 1
…
29 SC30 0 1
30 SC31 0 1
31 SC32 0 1
Analog Inputs
--------------------------------------------------------------------------------
INDEX POINT LABEL EVENT CLASS SCALE FACTOR DEADBAND
0 AI401 2 1.0000 100
1 AI402 2 1.0000 100
2 AI403 2 1.0000 100
…
95 FREQ 2 1.0000 100
96 3V2 2 10.0000 100
97 3I2 2 10.0000 100
98 IA_ANG 2 100.0000 100
99 IB_ANG 2 100.0000 100
