Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Appendix F
IEC 61850 Communications
Instruction Manual
Features
The SEL-2414 device supports the following features using Ethernet and
IEC 61850:
SCADA. Use as many as six MMS sessions of buffered and unbuffered reports.
Remote bits (RB01–RB32) are mapped to the RBGGIO Logical Node.
See Table F.3 and Table F.5 for details on the logical nodes associated
with these bits. This information is useful for issuing controls with an
MMS browser. Control inputs only support the direct-with-normal-secu-
rity control model.
NOTE: The SEL-2414 supports one
CID file, which should be transferred
only if a change in the device
configuration is required. If an invalid
CID file is transferred, the device will
no longer have a valid IEC 61850
configuration, and the protocol will
stop operating. To restart protocol
operation, a valid CID must be
transferred to the device.
Real-Time Status and Control. Use GOOSE with as many as 16 incoming
(receive) and as many as 8 outgoing (transmit) messages. Controls only
support the direct-with-normal-security control model. Remote Bits
(RB01–RB32), Virtual Bits (VB001–VB128) and Remote Analogs
(RA001–RA128) can also be mapped from GOOSE receive messages using
ACSELERATOR
Architect
®
SEL-5032 Software.
Configuration. Use FTP client software or ACSELERATOR Architect to trans-
fer the Substation Configuration Language (SCL) Configured IED
Description (CID) files to the device.
Commissioning and Troubleshooting. Use software such as MMS Object
Explorer and AX-S4 MMS from Sisco, Inc., to browse the device logical
nodes and verify functionality.
IEC 61850 Configuration
ACSELERATOR Architect
The ACSELERATOR Architect software enables protection and integration engi-
neers to design and commission IEC 61850 substations containing SEL IEDs.
Engineers can use
ACSELERATOR Architect to:
➤ Organize and configure all SEL IEDs in a substation project
➤ Configure incoming and outgoing GOOSE messages
➤ Read non-SEL IED Capability Description (ICD) and Configured
IED Description (CID) files and determine the available
IEC 61850 messaging options
➤ Load device settings and IEC 61850 CID files into SEL IEDs
