F.4 IEC 61850 Communications
Logical Nodes
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Table F.4 shows the LNs associated with control elements defined as Logical
Device CON.
Table F.5 shows the LNs associated with measuring elements defined as Logical
Device MET.
INEGGIO19 Ind01.stVal to Ind08.stVal Digital Inputs (IN501 to IN508)—Slot E
INEEGGIO20 Ind01.stVal to Ind08.stVal Edge Trigger Operator (IN501E to IN508E)—Slot E
OUTEGGIO21 Ind01.stVal to Ind08.stVal Digital Outputs (OUT501 to OUT508)—Slot E
INZGGIO22 Ind01.stVal to Ind08.stVal Digital Inputs (IN601 to IN608)—Slot Z
INZEGGIO23 Ind01.stVal to Ind08.stVal Edge Trigger Operator (IN601E to IN608E)—Slot Z
OUTZGGIO24 Ind01.stVal to Ind08.stVal Digital Outputs (OUT601 to OUT608)—Slot Z
VBGGIO25 Ind001.stVal to Ind128.stVal Virtual Bits (VB001 to VB128)
Table F.3 Logical Device: ANN (Annunciation) (Sheet 2 of 2)
Logical Nodes Status or Measurand Device Word Bits or Analog Quantities
Table F.4 Logical Device: CON (Control)
Logical Nodes Status and Control Device Word Bits
RBGGIO1 Status
SPCSO01.stVal to SPCSO32.stVal
Control
SPCSO01.ctlVal to SPCSO32.ctlVal
Remote Bits (RB01 to RB32)
Table F.5 Logical Device: MET (Metering) (Sheet 1 of 5)
Logical Nodes Measurand Comment
Thermal (RTD) Metering
RTDMTHI1 InTmp01.instMag to InTmp10.instMag Internal RTDs—Slot D
a
UTCMTHI1 InTmp01.instMag to InTmp10.instMag General Purpose Internal RTD/TCs—Slot D
b
THERMMTHE1 ExTmp01.instMag to ExTmp10.instMag External RTDs
c
THERMMTHM1 MAMBT
T1OILM–T3OILM
T1OILC–T3OILC
T1HS–T3HS
T1FAA–T3FAA
T1RLOL–T3RLOL
T1LLOL–T3LLOL
T1TLL–T3TLL
T1LOAD–T3LOAD
TEC1–TEC3
Measured Ambient Temperature
Measured Top-Oil Temperature
Calculated Top-Oil Temperature
Calculated Hot-Spot Temperature
Insulation Aging Acceleration Factor
Daily Rate of Loss-of-Life
Total Accumulated Loss-of-Life
Time to “Total Accumulated Loss-of-Life” alarm
Load current in per-unit value
Thermal Element Condition
d
d
d
d
d
d
d
Fundamental Metering
METMMXU1 Hz.instMag Instantaneous, Frequency
e, f
METMMXU1 A.phsA.instCVal.mag Instantaneous, Current Magnitude, Phase A
e
METMMXU1 A.phsB.instCVal.mag Instantaneous, Current Magnitude, Phase B
e
METMMXU1 A.phsC.instCVal.mag Instantaneous, Current Magnitude, Phase C
e
METMMXU1 A.neut.instCVal.mag Instantaneous, Current Magnitude, Neutral
e
METMMXU1 A.res.instCVal.mag Instantaneous, Current Magnitude, Residual
e
METMMXU1 A.nseq.instCVal.mag Instantaneous, Current Magnitude, Negative Sequence
e
METMMXU1 A.phsA.instCVal.ang Instantaneous, Current Angle, Phase A
e
METMMXU1 A.phsB.instCVal.ang Instantaneous, Current Angle, Phase B
e
METMMXU1 A.phsC.instCVal.ang Instantaneous, Current Angle, Phase C
e
METMMXU1 A.neut.instCVal.ang Instantaneous, Current Angle, Neutral
e
METMMXU1 A.res.instCVal.ang Instantaneous, Current Angle, Residual
e
