6.12
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Settings
Global Settings (SET G Command)
Universal
Temperature Inputs
Global Settings (SET G Command)
Use the serial command SET G <Enter> to access the Global settings category.
In the Global settings category, we set the Messenger Points phase rotation, rated
frequency, CT and PT connections, date format, debounce times for each input of
each installed digital input I/O card (DI card), data reset, front-panel disable set-
ting, time synchronization source, and voltage correction factor.
General Settings
The phase rotation setting tells the device your phase labeling standard. Set
PHROT equal to ABC when B-phase lags A-phase by 120 degrees. Set PHROT
equal to ACB when B-phase leads A-phase by 120 degrees.
Table 6.12 Input Settings for Internal General Purpose RTD/TC Card in Slot 3
Setting
Prompt
Description Setting Range
Setting Name :=
Factory D efaul t
TEMP1TY Internal RTD/TC Card PT100, NI100, NI120,
CU10, J, K, T, E, NONE
None
TEMP2TY Internal RTD/TC Card PT100, NI100, NI120,
CU10, J, K, T, E, NONE
None
TEMP3TY Internal RTD/TC Card PT100, NI100, NI120,
CU10, J, K, T, E, NONE
None
TEMP4TY Internal RTD/TC Card PT100, NI100, NI120,
CU10, J, K, T, E, NONE
None
TEMP5TY Internal RTD/TC Card PT100, NI100, NI120,
CU10, J, K, T, E, NONE
None
TEMP6TY Internal RTD/TC Card PT100, NI100, NI120,
CU10, J, K, T, E, NONE
None
TEMP7TY Internal RTD/TC Card PT100, NI100, NI120,
CU10, J, K, T, E, NONE
None
TEMP8TY Internal RTD/TC Card PT100, NI100, NI120,
CU10, J, K, T, E, NONE
None
TEMP9TY Internal RTD/TC Card PT100, NI100, NI120,
CU10, J, K, T, E, NONE
None
TEMP10TY Internal RTD/TC Card PT100, NI100, NI120,
CU10, J, K, T, E, NONE
None
Table 6.13 General Global Settings
Setting Prompt Setting Range
Setting Name :=
Factory Defaul t
Phase Rotation ABC, ACB PHROT := ABC
Rated Frequency 50, 60 Hz FNOM := 60
Transformer Connection DELTA, WYE DELTA_Y := WYE
Date Format MDY, YMD, DMY DATE_F := MDY
