Sel 2414 - SHOW Command (Show;View Settings); SNS Command (Displays SER Settings)

7.25
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Communications
ASCII Commands
SHOW Command
(Show/View Settings)
When showing settings, the device displays the settings label and the present
value from nonvolatile memory for each setting class as shown in Table 7.45.
Append s and the specific setting name you want to view in the SHOW com-
mand to immediately jump to the setting. If s (and the setting name) is not
included, the device presents settings beginning with the first one in the group.
SNS Command
(Displays SER
Settings)
Available as a compressed command only, the SNS command displays the SER
settings in Compressed ASCII format, as shown in Table 7.46.
The SER trigger elements are gathered in groups of eight elements to be dis-
played on each line of the report, as shown in Figure 7.5. The last line of the
report may have fewer than eight elements. Each line is formatted as a comma-
separated list of quoted SER trigger elements, followed by a quoted hexadecimal
representation of the checksum. The checksum is calculated from the first quote
mark of the line up to the last comma before the checksum. If there are no SER
trigger elements (i.e., all SER settings are NA), no lines are generated for the
report.
Table 7.45 SHO Command
Command Description Access Level
SHO s Show Device settings 1
SHO L s Show Logic settings 1
SHO G s Show Global settings 1
SHO POR n s Show serial port settings, n specifies either Port F or
Ports 1 through 4; defaults to the active port if not
listed.
1
SHO R s Show report settings such as Sequential Events
Recorder (SER) and Event Report (ER) settings
1
SHO F s Show front-panel settings 1
SHO DN s Show DNP3 settings 1
Table 7.46 SNS Command
Command Description Access Level
SNS The SNS command displays the SER trigger elements
(entered with the SET R SERn (n = 1 through 4) com-
mand) in Compressed ASCII format.
0
=SNS <Enter>
"IN101","IN102","IN301","IN302","IN303","IN304","IN305","IN306","0CE4"
"IN307","IN308","IN401","IN402","IN403","IN404","IN405","IN406","0CFA"
"IN407","IN408","IN501","IN502","IN503","IN504","IN505","IN506","0D02"
"IN507","IN508","IN601","IN602","IN603","IN604","IN605","IN606","0D0A"
"IN607","IN608","0349"
=
Figure 7.5 SER Settings, Using the SNS Command
