Sel 2414 - Internal RTD Inputs; External RTD Inputs

6.11
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Settings
Device Settings (SET Command)
Internal RTD Inputs
External RTD Inputs
Table 6.10 Input Settings for Internal RTD Card in Slot 3
Setting
Prompt
Description Setting Range
Setting Name :=
Factory Default
IRTD1TY Internal RTD Card PT100, NI100, NI120,
CU10, NONE
None
IRTD2TY Internal RTD Card PT100, NI100, NI120,
CU10, NONE
None
IRTD3TY Internal RTD Card PT100, NI100, NI120,
CU10, NONE
None
IRTD4TY Internal RTD Card PT100, NI100, NI120,
CU10, NONE
None
IRTD5TY Internal RTD Card PT100, NI100, NI120,
CU10, NONE
None
IRTD6TY Internal RTD Card PT100, NI100, NI120,
CU10, NONE
None
IRTD7TY Internal RTD Card PT100, NI100, NI120,
CU10, NONE
None
IRTD8TY Internal RTD Card PT100, NI100, NI120,
CU10, NONE
None
IRTD9TY Internal RTD Card PT100, NI100, NI120,
CU10, NONE
None
IRTD10TY Internal RTD Card PT100, NI100, NI120,
CU10, NONE
None
Table 6.11 Input Settings for External RTD from SEL-2600 Devices
Setting
Prompt
Description Setting Range
Setting Name :=
Factory Default
ERTD1TY External RTD from
SEL
-2600 Devices
PT100, NI100, NI120,
CU10, NONE
None
ERTD2TY External RTD from
SEL
-2600 Devices
PT100, NI100, NI120,
CU10, NONE
None
ERTD3TY External RTD from
SEL
-2600 Devices
PT100, NI100, NI120,
CU10, NONE
None
ERTD4TY External RTD from
SEL
-2600 Devices
PT100, NI100, NI120,
CU10, NONE
None
ERTD5TY External RTD from
SEL
-2600 Devices
PT100, NI100, NI120,
CU10, NONE
None
ERTD6TY External RTD from
SEL
-2600 Devices
PT100, NI100, NI120,
CU10, NONE
None
ERTD7TY External RTD from
SEL
-2600 Devices
PT100, NI100, NI120,
CU10, NONE
None
ERTD8TY External RTD from
SEL
-2600 Devices
PT100, NI100, NI120,
CU10, NONE
None
ERTD9TY External RTD from
SEL
-2600 Devices
PT100, NI100, NI120,
CU10, NONE
None
ERTD10TY External RTD from
SEL
-2600 Devices
PT100, NI100, NI120,
CU10, NONE
None
ERTD11TY External RTD from
SEL
-2600 Devices
PT100, NI100, NI120,
CU10, NONE
None
ERTD12TY External RTD from
SEL
-2600 Devices
PT100, NI100, NI120,
CU10, NONE
None
