6.10
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Settings
Device Settings (SET Command)
but the device converts all lowercase characters to uppercase. Although the
device accepts alphanumeric characters, the name AO301NAM setting must
begin with an alpha character (A–Z) and not a number.
NOTE: The AOx0yNAM setting
cannot accept the following:
Analog Quantities
Duplicate Names
Other AI Names
In this example, assume we want to display the transformer temperature measure-
ment from Analog Input AI301 (relabeled TX_TEMP) on an instrument in the
station control room that operates on 4–20 mA. We install an analog output card
in Slot D, and set the card as shown in Figure 6.5.
Table 6.9 Output Setting for a Card in Slot 3
Setting
Prompt
Description Setting Range
Setting Name :=
Factory Default
AO301AQ Analog Quantity Analog Quantity Value AO301AQ := OFF
AO301NAM Instrument Tag Name 8 characters 0–9, A–Z, _ AO301NAM := AO30I
AO301TYP Type I, V AO301TYP := I
AO301AQL Analog Quantity Low –2147483647.000 to
+2147483647.000
AO301AQL := 4.000
AO301AQH Analog Quantity High –2147483647.000 to
+2147483647.000
AO301AQH := 20.000
a
AO301L
a
For AO301TYP = I
Low Output Value –20.480 to +20.480 mA AO301L := 4.000
a
AO301H High Output Value –20.480 to +20.480 mA AO301H := 20.000
b
AO301L
b
For AO301TYP = V
Low Output Value –10.240 to +10.240 V AO301L := 0.000
b
AO301H High Output Value –10.240 to +10.240 V AO301H := 10.000
=>>SET AO401AQ TERSE <Enter>
Device
Analog Output 401 Settings
AO401 Analog Quantity (1 analog quantity)
AO401AQ := OFF
? AI301 <Enter>
AO401 Type (I,V) AO401TYP:= I ? <Enter>
AO401 Analog Quantity Low (-2147483647.000 to 2147483647.000)
AO401AQL:= 4.000 ? 4 <Enter>
AO401 Analog Quantity High (-2147483647.000 to 2147483647.000)
AO401AQH:= 20.000 ? 20 <Enter>
AO401 Low Output Value (-20.480 to 20.480 mA) AO401L := 4.000 ? <Enter>
AO401 High Output Value (-20.480 to 20.480 mA) AO401H := 20.000 ? <Enter>
Analog Output 402 Settings
AO402 Analog Quantity (1 analog quantity)
AO402AQ := OFF
? END <Enter>
Save changes (Y,N)? Y <Enter>
Settings Saved
=>>
Figure 6.5 Analog Output Settings
