8.7
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Front-Panel Operations
Human-Machine Interface
Access Level 2 Password Entry
When you try to perform an Access Level 2 activity, the device determines
whether you have entered the correct Access Level 2 password since the front-
panel inactivity timer expired. If you have not, the device displays the screen
shown in Figure 8.11 for you to enter the password.
Figure 8.11 Password Entry Screen
See PASSWORD Command (View/Change Passwords) on page 7.21 for the list of
default passwords and for more information on changing passwords.
Front-Panel Time-Out
To help prevent unauthorized access to password-protected functions, the
SEL-2414 provides a front-panel time-out, setting FP_TO. A timer (5 minutes
default setting) is reset every time a front-panel pushbutton is pressed. Once the
time-out period has expired, the access level is reset to Access Level 1.
Front-Panel Menus
and Screens
Navigating the Front-Panel Menus
The SEL-2414 front panel gives you access to most of the information that the
device measures and stores. You can also use front-panel controls to view or
modify device settings. All of the front-panel functions are accessible through
use of the six-button keypad and LCD display, as shown in Figure 8.12.
Password=
Del Clr Accept
A B C D E F G H
I J K L M N O P
Q R S T U V W X
Y Z . . . . . .
a b c d e f g h
i j k l m n o p
q r s t u v w x
y z . . . . . .
0 1 2 3 4 5 6 7
8 9 . . . . . .
! " # $ % & ' (
) * + , - . / :
; < = > ? @ [ \
] ^ _ ` { | } ~
