SET Command
(Change Settings)
The SET command is for viewing or changing the device settings, as shown in
Table 7.43. Append TERSE to skip the settings display after the last setting. Use
this parameter to speed up the SET command. If you want to review the settings
before saving, do not use the TERSE option. The Alarm Contact closes for
1 second when saving new settings.
Append s and the specific setting name you want to change in the SET command
to immediately jump to the setting. For example if s is not entered, the device
starts at the first setting. For example, to directly jump to the FMR1 setting in the
Report setting category, enter SET R FMR1 TERSE <Enter>.
When you issue the SET command, the device presents a list of settings one at a
time. Enter a new setting or press <Enter> to accept the existing setting, as
shown in Table 7.44.
The device checks each setting to ensure that it is within the allowed range. If the
setting is not within the allowed range, the device generates an
Out of Range
message and prompts you for the setting again. When all the settings are entered,
the device displays the new settings and prompts you for approval to enable them.
Answer Y <Enter> to enable the new settings. The device is disabled for no lon-
ger than one second while saving the new settings. The SALARM Device Word
bit asserts momentarily and the ENABLED LED extinguishes while the device is
disabled.
Table 7.43 SET Command
Command Description Access Level
SET s TERSE Set Device settings 2
SET L s TERSE Set Logic settings 2
SET G s TERSE Set Global settings 2
SET POR n s
TERSE
Set serial port settings, depending on the device con-
figuration, n specifies either Port F or Ports 2 through
4; defaults to the active port if not listed.
2
SET R s TERSE Set SER report settings 2
SET F s TERSE Set front-panel settings 2
SET DN s TERSE Set DNP3 settings 2
Table 7.44 SET Command Editing Keystrokes
Press Key Results
<Enter> Retains the setting and moves to the next setting
^ <Enter> Returns to the previous setting
< <Enter> Returns to the previous setting category
> <Enter> Moves to the next setting category
END
<Enter>
Exits the editing session, then prompts you to save the settings
<Ctrl+X> Aborts the editing session without saving changes
