5.10
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Metering and Monitoring
Monitoring
Monitoring
The SEL-2414 monitor data fall into the following categories:
Thermal Element
Application Description
The SEL-2414 provides a thermal element based on IEEE Standard
C57.91-1995, IEEE Guide for Loading Mineral-Oil-Immersed Power Transform-
ers. Use this element to activate a control action or issue a warning or alarm when
your transformer overheats or is in danger of excessive insulation aging or loss of
life. Capture current hourly or daily data about your transformer using the ther-
mal event report. The data acquisition interval is one minute. This very short time
interval makes the element suitable for both thermal protection and control func-
tions.
=>>MET RA <Enter>
SEL-2414 Date: 02/15/2005 Time: 13:42:23
DEVICE Time Source: External
RA01 1.00
RA02 -32767.00
RA03 -1.00
RA04 0.00
RA05 1000.59
RA06 -1000.61
RA07 2414.01
RA08 2410.99
RA09 98303.00
RA10 -98303.00
RA11 -38400.00
RA12 -65536.00
RA13 0.00
RA14 0.00
RA15 0.00
• •
• •
• •
RA126 0.00
RA127 0.00
RA128 0.00
=>>
Figure 5.9 Device Response to the MET RA Command
Monitoring Command
Transformer
Thermal
➤ Thermal Status THE
➤ Event THE [n]
➤ Daily Profile THE D
➤ Hourly Profile THE H
Through-Fault TFE
Other
Analog Signal Profiling PRO
