C.12
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
SEL Communications Processors
SEL Communications Processor Example
Device Word Bits
Information
Table C.13 lists the Device Word bit data available in the SEL communications
processor TARGET data region 2 (D2).
Control Points
The SEL communications processor can automatically pass control messages,
called Fast Operate messages, to the SEL-2414. You must enable Fast Operate
messages by using the FASTOP setting in the SEL-2414 port settings for the port
DATE 2005h char
YEAR 2006h char
HOUR 2007h char
MIN 2008h char
SECONDS 2009h char
MSEC 200Ah int
IA 200Bh float
IB 200Dh float
IC 200Fh float
IN 2011h float
IG 2013h float
3I2 2015h float
FREQ 2017h float
Table C.12 Communications Processor SEL-2414 METER Region Map for
Current Cards Only (Sheet 2 of 2)
Item Starting Address Ty pe
Table C.13 Communications Processor TARGET Region
Address
Device Word Bits (in Bits 7–0)
7 6 5 4 3 2 1 0
2804h
STSET
2805h See Table H.1, Row 0
2806h See Table H.1, Row 1
2807h See Table H.1, Row 2
2808h See Table H.1, Row 3
2809h See Table H.1, Row 4
280Ah See Table H.1, Row 5
280Bh See Table H.1, Row 6
280Ch See Table H.1, Row 6
280Dh See Table H.1, Row 8
280Eh See Table H.1, Row 9
280Fh See Table H.1, Row 10
•
•
•
•
•
•
2866h See Table H.1, Row 119
