8.11

Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor

Front-Panel Operations

Human-Machine Interface

traditional panel switches, and perform isolation, open, close or pulse operations.

With the settings as per the example in Section 6: Settings (see Local Bits on

page 8.5 for more information), Local bit 1 replaces a supervisory switch.

Figure 8.18 shows the screens in closing the supervisory switch. In this opera-

tion, Local bit LB01 is deasserted (SUPER SW = OPEN), and changes to

asserted (SUPER SW = CLOSE) as shown in the final screen of Figure 8.18.

Set/Show Menu

Figure 8.19 shows the SET/SHO menu of the SEL-2414.

Each settings class includes headings that create subgroups of associated settings.

Select the heading that contains the setting of interest, then navigate to the partic-

ular setting. View or edit the setting by pressing ENT. For text settings, use the

four navigation pushbuttons to scroll through the available alphanumeric and spe-

cial character settings matrix. For numeric settings, use the Left Arrow and Right

Arrow pushbuttons to select the digit to change and the Up Arrow and Down Arrow

pushbuttons to change the value. Press ENT to enter the new setting. Setting

changes can also be made using the ASCII SET commands via a communica-

tions port.

Figure 8.18 Main Menu and Control Submenu

Meter

Events

Targets

Control

Set/Show

Status

Quit

LOCAL BITS

SUPER SW = OPEN

CONTROL

Local Bits

Outputs

(Control selected)

(Local selected)

(SUPERVISORY SW = selected)

SUPER SW = CLOSE

OPEN

Yes No

SUPER SW = OPEN

(Close selected)

(Move cursor to Yes

press enter)

Figure 8.19 Main Menu and SET/SHO Submenu

SET/SHOW

Device

Logic

Global

Port

Date

Time

Password
