C.8
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
SEL Communications Processors
SEL Communications Processor Example
Table C.6 shows the SEL communications processor automessage (Set A) set-
tings for data collection from the SEL-2414.
Table C.7 shows the map of regions in the SEL communications processor for
data collected from the SEL-2414. Use the MAP n command to view these data.
Device Metering Data
Table C.8 shows the list of meter data available in the SEL communications pro-
cessor and the location and data type for the memory areas within D1 (Data
Region 1) for a device configured with both voltage (wye-connected) and current
cards. The type field indicates the data type and size. The int type is a 16-bit inte-
ger. The float type is a 32-bit IEEE floating point number. Use the VIE n:D1
(n = port number) command to view these data.
Table C.6 SEL Communications Processor Port 1 Automatic Messaging
Settings
Setting Name Setting Description
AUTOBUF Y Save unsolicited messages
STARTUP ACC\nOTTER\n Automatically log-in at Access Level 1
SEND_OPER Y Send Fast Operate messages for remote bit control
REC_SER N Automatic Sequential Event Recorder data
collection disabled
NOCONN NA No SEL
OGIC
®
control equation entered to
selectively block connections to this port
MSG_CNT 2 Two automessages
ISSUE1 P00:00:01.0 Issue Message 1 every second
MESG1 20METER Collect metering data
ISSUE2 P00:00:01.0 Issue Message 2 every second
MESG2 20TARGET Collect Device Word bit data
ARCH_EN N Archive memory
USER 0 No USER region registers reserved
Table C.7 SEL Communications Processor Port 1 Region Map
Region
Data Collection
Message Type
Region Name Description
D1 Binary METER Device metering data
D2 Binary TARGET Device Word bit data
D3–D8 n/a n/a Unused
A1–A3 n/a n/a Unused
USER n/a n/a Unused
Table C.8 Communications Processor METER Region Map for Both Voltage
(Wye-Delta Connected) and Current Cards (SEL
ECT AVI an d S ELECT 4 CT)
(Sheet 1 of 2)
Item Starting Address Type
_YEAR 2000h int
DAY_OF_YEAR 2001h int
TIME(ms) 2002h Int[2]
MONTH 2004h char
DATE 2005h char
