Sel 2414 - GOOSE Command

7.13
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Communications
ASCII Commands
For more information on event reports, see Section 9: Analyzing Events.
GOOSE Command
Use the GOOSE command to display transmit and receive GOOSE messaging
information, which can be used for troubleshooting. The GOOSE command
variants and options are shown in Table 7.28.
The information displayed for each GOOSE IED is described in the following
table.
Tab le 7.27 HI STO RY Co m man d
Command Description Access Level
HIS Return event histories with the oldest at the bottom of
the list and the most recent at the top of the list
1
HIS n Return event histories with the oldest at the bottom of
the list and the most recent at the top of the list, begin-
ning at event n.
1
HIS C Clear/reset the event history and all corresponding
event reports from nonvolatile memory.
1
Table 7.28 GOOSE Command Variants
Command Variant Description Access Level
GOOSE Display Goose information. 1
GOOSE count Display GOOSE information count times. 1
IED Description
Transmit
GOOSE Control
Reference
This field represents the GOOSE control reference information that
includes the IED name, ldInst (Logical Device Instance), LN0 lnClass
(Logical Node Class), and GSEControl name (GSE Control Block
Name) (e.g., SEL_2414_1CFG/LLN0$GO$GooseDSet13).
Receive
GOOSE Control
Reference
This field represents the goCbRef (GOOSE Control Block Reference)
information that includes the iedName (IED name), ldInst (Logical
Device Instance), LN0 lnClass (Logical Node Class), and cbName
(GSE Control Block Name) (e.g.,
SEL_2414_1CFG/LLN0$GO$GooseDSet13).
MultiCastAddr
(Multicast Address)
This hexadecimal field represents the GOOSE multicast address.
Ptag
This three-bit decimal field represents the priority tag value, where
spaces are used if the priority tag is unknown.
Vlan
This 12-bit decimal field represents the virtual LAN (Local Area
Network) value, where spaces are used if the virtual LAN is unknown.
StNum (State
Number)
This hexadecimal field represents the state number that increments with
each state change.
SqNum (Sequence
Number)
This hexadecimal field represents the sequence number that increments
with each GOOSE message sent.
TTL (Time to Live) This field contains the time (in ms) before the next message is expected.
Code
This text field contains warning or error condition text when
appropriate that is abbreviated as follows:
