Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Installation
Card Configuration
Digital Input Card
(8 DI)
Supported in any expansion slot (Slot C through Slot Z), this card has eight digi-
tal inputs. Table 2.12 shows the terminal allocation.
Digital Output Card
(8 DO)
Supported in any expansion slot (Slot C through Slot Z), this card has eight con-
tact outputs. Table 2.13 shows the terminal allocation. When ordering, select
eight normally open (Form A) contact outputs, eight normally closed (Form B)
contact outputs, six normally open (Form A) and two normally closed (Form B)
contact outputs, or six normally closed (Form B) and two normally open (Form
A).
Table 2.12 Eight Digital Input Card (SELECT 8 DI) Terminal Allocation
Term i n a l s Label Description
IN01, drives INx01 element
IN02, drives INx02 element
IN03, drives INx03 element
IN04, drives INx04 element
IN05, drives INx05 element
IN06, drives INx06 element
IN07, drives INx07 element
IN08, drives INx08 element
07
08
05
06
03
04
01
02
IN_01
IN_02
IN_03
IN_04
INPUTS:
13
14
11
12
09
10
IN_05
IN_06
IN_07
15
16
IN_08
NOTE: You can run three 8 DO
boards at 85 V in accordance with
UL 61010-1.
Table 2.13 Digital Output Card (SELECT 8 DO) Terminal Allocation
Te r m in al s Form A Form B
6 Form A/
2Form B
2 Form A/
6Form B
Description
OUT01, driven by OUTx01 SELOGIC
®
equation
OUT02, driven by OUTx02 SEL
OGIC equation
OUT03, driven by OUTx03 SEL
OGIC equation
OUT04, driven by OUTx04 SEL
OGIC equation
OUT05, driven by OUTx05 SEL
OGIC equation
OUT06, driven by OUTx06 SEL
OGIC equation
OUT07, driven by OUTx07 SEL
OGIC equation
OUT08, driven by OUTx08 SEL
OGIC equation
OUT_01
01
02
OUT_02
03
04
OUT_03
05
06
OUT_04
07
08
OUT_05
09
10
OUT_06
11
12
OUT_07
13
14
OUT_08
15
16
OUT_01
01
02
OUT_02
03
04
OUT_03
05
06
OUT_04
07
08
OUT_05
09
10
OUT_06
11
12
OUT_07
13
14
OUT_08
15
16
OUT_0 1
OUT_02
OUT_03
OUT_04
OUT_05
OUT_06
OUT_07
OUT_08
08
05
06
02
04
09
03
10
11
12
13
14
15
16
07
01
OUT_0 1
OUT_02
OUT_03
OUT_04
OUT_05
OUT_06
OUT_07
OUT_08
08
05
06
02
04
09
03
10
11
12
13
14
15
16
07
01
