Sel 2414 - IDENTIFICATION Command; IRIG Command; L_D Command (Load Firmware)

7.15
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Communications
ASCII Commands
IDENTIFICATION
Command
Available as a compressed command only, use the ID command to extract device
identification codes, as shown in Table 7.29.
IRIG Command
Use the IRI command to read the demodulated IRIG-B time code at the serial
port or IRIG-B input, and to force immediate synchronization of the internal
clock with the IRIG-B signal (see Table 7.30). If an IRIG-B signal is present at
the serial port or IRIG-B input, the device automatically synchronizes the internal
clock with the IRIG-B signal in a time period not exceeding one minute. It is not
necessary to issue the IRI command for this automatic one-minute synchroniza-
tion. If you are testing the device and do not want to wait for the one-minute syn-
chronization, then issue the IRI command to immediately force the device to
synchronize with the IRIG-B signal. You can also use the IRI command to deter-
mine if the device is properly reading the IRIG-B signal.
To force the device to synchronize to IRIG-B, enter the following command:
=>IRI <Enter>
If the device successfully synchronizes to IRIG, it sends the following header and
access level prompt:
SEL-2414 Date: 04/12/2005 Time: 15:41:29
DEVICE
=>
If no IRIG-B code is present at the serial port input or if the code cannot be read
successfully, the device responds:
IRIG-B DATA ERROR
=>
L_D Command
(Load Firmware)
Use the L_D command to load firmware, as shown in Table 7.31. See
Appendix A: Firmware and Manual Versions for information on changes to the
firmware and instruction manual. See Appendix B: Firmware Upgrade Instruc-
tions for further details on downloading firmware.
Table 7.29 IDENTIFICATION Command
Command Description Access Level
ID Return a list of device identification codes, as shown
below:
=ID <Enter>
"FID=SEL-2414-R200-V0-Z002002-D20070810","08C8"
"BFID=BOOTLDR-X300-V0-Z000000-D20050221","0947"
"CID=C7D8","0273"
"DEVID=SEL-2414","03F2"
"DEVCODE=62","030F"
"PARTNO=241401A0X5X7185100","0666"
"CONFIG=111120","0389"
0
The following is also displayed if 61850 is available:
"iedName=SEL_2414_1","05FB"
"type=SEL_2414","047A"
"configVersion=ICD-SEL-2414-R200-V0-Z002002-
D20070730","0E52"
Tab le 7.30 IR IG Co mm an d
Command Description Access Level
IRI Force synchronism of internal control clock to IRIG-B
time-code input.
1
