Sel 2414 - Device Settings (SET Command); Transformer Settings

6.5
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Settings
Device Settings (SET Command)
As you enter Device settings, the device checks the setting entered against the
range for the setting as published on the device settings sheets. If any setting
entered falls outside the corresponding range for that setting, the device immedi-
ately responds
Out of Range and prompts you to reenter the setting. In addition
to the immediate range check, several of the settings have interdependency
checks with other settings. The device checks setting interdependencies after you
answer Y to the
Save Settings? prompt, but before the settings are stored. If any
of these checks fail, the device issues an error message, and returns you to the
settings list for a correction.
Device Settings (SET Command)
Under the Device setting category, we set the device and terminal identifiers, set-
tings pertaining to the analog (transducer) input (AI) cards, analog output (AO)
cards, and transformers. The SEL-2414 displays the Device and Terminal Identi-
fier strings at the top of responses to serial port commands identifying messages
from individual devices. Enter up to 16 characters, including capital letters A–Z,
numbers 0–9, periods (.), dashes (-), and spaces. Table 6.5 shows the device and
terminal identifiers settings.
Transformer Settings
For devices with a current card, a voltage card, or both current and voltage cards
installed, the device prompts for the settings as shown in Table 6.6.
END <Enter> Exits the editing session, then prompts you to save the settings
<Ctrl+X> Aborts the editing session without saving changes
Tab le 6.4 SET Command Editing Keystrokes (Sheet 2 of 2)
Press Key Results
Table 6.5 Device and Terminal Identifiers
Setting Prompt Setting Range Setting Name := Factory Default
Device ID 16 Characters DID := SEL-2414
Terminal ID 16 Characters TID := DEVICE
Table 6.6 Current and Voltage Transformer Settings
Setting Prompt Setting Range Setting Name := Factory Default
Current Transformer
Ratio
1–5000 CTR := 250
Additional Current
Transformer Ratio
1–5000 CTRX := 250
Additional Current
Transformer Ratio
Winding 1
1–5000 CTRX_W1 := 250
Additional Current
Transformer Ratio
Winding 2
1–5000 CTRX_W2 := 250
Additional Current
Transformer Ratio
Winding 3
1–5000 CTRX_W3 := 250
Potential Trans-
former Ratio
1.00–10000.00 PTR := 35.00
