Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Logic Functions
Overview
Mathematical
Operators
Mathematical operators can only be used in SELOGIC Math Variables; the opera-
tors are shown in Table 4.3. Use the mathematical operators with Analog Quanti-
ties (e.g., IA, IB, IC); including Math Variables (MV01–MV32). See SEL
OGIC
Control Equation Operators for more details.
Function Blocks
Function block outputs can be used in any SELOGIC equation; the function blocks
and their outputs are shown in Table 4.4. Likewise, logical operators can be used
in any of the SEL
OGIC equations that drive the function blocks. Each function
block is described in more detail in General Logic Functions.
Comparison
Greater Than >
Greater Than or Equal >=
Equality =
Less Than or Equal <=
Less Than <
Inequality <>
Table 4.2 Logical Operators (Sheet 2 of 2)
Operation Operator
Table 4.3 Mathematical Operators (Use in Math Variables)
Operation Operator
Negation –
Multiply *
Divide /
Add +
Subtract -
Tab le 4. 4 Fu nct i on B l ocks
Function Output
Latches LT01–LT32
Va ri ab le s SV 0 1– SV 64
Timers SV01T–SV64T
Counters SC01–SC32
