7.11
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Communications
ASCII Commands
COUNTER Command
(Counter Values)
The device generates the values of the 32 counters in response to the COU com-
mand, as shown in Table 7.20.
CPROFILE Command
(Compressed Signal
Profile Values)
The CPR command retrieves analog signal profile data in Compressed ASCII
format, as shown in Table 7.21.
CSTATUS Command
(Compressed Status)
The CST command generates a device status report in Compressed ASCII for-
mat, as shown in Table 7.22.
CSUMMARY Command
(Compressed
Summary)
The CSU command retrieves the event summary information from the last event
report in Compressed ASCII format, as shown in Table 7.23.
DATE Command
(View/Change Date)
Use the DATE command to view and set the device date, as shown in Table 7.24.
]
The device can overwrite the date entered by using other time sources such as
IRIG. Enter the DATE command with a date to set the internal clock date. Sepa-
rate the month, day, and year parameters with slashes. Set the year in 4-digit form
(for dates 2000–2099). Global setting DATE_F sets the date format.
ETHERNET Command
The ETH command displays the status report of both Ethernet ports, including
settings and performance.
Table 7.20 COUNTER Command
Command Description Access Level
COU n Display the values of the SELOGIC counters n times 1
Table 7.21 CPROFILE Command
Command Description Access Level
CPR Display analog signal profile data 1
Table 7.22 CSTATUS Command
Command Description Access Level
CST Return the device status in Compressed ASCII format 1
Table 7.23 CSUMMARY Command
Command Description Access Level
CSU Return the most recent event summary (with label
lines) in Compressed ASCII format
1
Tab le 7.24 DAT E Co mm an d
Command Description Access Level
DAT Display the internal clock date 1
DAT date Set the internal clock date
(DATE_F set to MDY, YMD, or DMY)
1
