THE (Thermal Report)
The THERM command displays temperature inputs, thermal event reports,
hourly profile data or daily profile data, depending on the command statement.
There are several choices for the THE command, listed briefly below. Refer to
Section 5: Metering and Monitoring for a complete description of the thermal
monitoring reports.
The date entries in the examples for the THE H and THE D commands are
dependent on the Date Format setting DATE_F. If setting DATE_F = MDY, enter
the dates as in the above examples (Month/Day/Year). If setting DATE_F =
YMD, enter the dates Year/Month/Day.
If the requested THE hourly or daily profile records do not exist, the device
responds: Invalid Record. If there are no data in the hourly or daily profile
buffers, the device responds:
No Data Available.
TIME Command
(View/Change Time)
The TIME command returns information about the SEL-2414 internal clock, as
shown in Table 7.52. You can also set the clock if you specify hours and minutes
(seconds data are optional). Separate the hours, minutes, and seconds with
colons.
Use the TIME hh:mm and TIME hh:mm:ss commands to set the internal clock
time. The value hh is for hours from 0–23; the value mm is for minutes from
0–59; the value ss is for seconds from 0–59. If you enter a valid time, the device
updates and saves the time in the nonvolatile memory, and displays the time you
just entered. If you enter an invalid time, the SEL-2414 responds with
Invalid
Time
.
Table 7.51 TFE Command Choices
Command Description Access Level
THE Displays a thermal monitor report that indicates
the present thermal status of the transformer.
1
THE C Clears the hourly profile, daily profile,
and thermal event data archives.
2
THE D x y Retrieves daily profile data from day x to day y.
If x and y are omitted, retrieves entire profile data.
If x or y is omitted, retrieves profile from day x (y) to
present.
1
THE H x y Retrieves hourly profile data from day x to day y.
If x and y are omitted, retrieves entire profile data.
If x or y is omitted, retries profile from day x (y) to
present.
1
THE n Displays saved thermal monitor report n
where n = 1 is the most recently saved report.
1
THE P n Loads preset value of accumulated insulation loss of
life.
2
THE R Clears the hourly profile, daily profile, and thermal
event data archives and resets the total loss-of-life val-
ues.
2
Table 7.52 TIM Command Definitions
Command Description Access Level
TIME Display the present internal clock time 1
TIME hh:mm Set the internal clock to hh:mm 2
TIME hh:mm:ss Set the internal clock to hh:mm:ss 2
