Getting Started
ACSELERATOR QuickSet
ACSELERATOR QuickSet
Overview
ACSELERATOR QuickSet
®
SEL-5030 Software is a powerful setting, event analy-
sis, and measurement tool that aids in setting, applying and using the SEL-2414.
Table 3.1 shows the suite of
ACSELERATOR QuickSet applications provided for
the SEL-2414.
Other PC software applications that support the SEL-2414 Transformer Monitor
are listed in Table 3.2.
Installation
Install ACSELERATOR QuickSet on your personal computer. Once ACSELERA-
TOR QuickSet is installed, launch the application and a launchpad similar to
Figure 3.4 will appear.
Tab le 3.1 ACSELERATOR QuickSet SEL-5030 Software
Terminal Provides a direct connection to the SEL device. Use this
communication method to interface directly with the device.
Rules Based Settings
Editor
Provides on-line or off-line device settings that include interdepen-
dency checks. Use this feature to create and manage settings for mul-
tiple devices in a database.
Event analysis Provides oscillography and other event analysis tools.
HMI Provides metering and control features.
Setting Database
Management
ACSELERATOR QuickSet uses a database to manage the settings of
multiple devices.
Help Provides general
ACSELERATOR QuickSet and device-specific
ACSELERATOR QuickSet context help.
Tab le 3. 2 S E L Sof twa re So lu ti on s
Part Number Product Name Description
SEL-5032 ACSELERATOR Architect
®
SEL-5032 Software
Configures IEC 61850 communications
SEL-5040
ACSELERATOR
®
Report Server
SEL-5040 Software
This application automatically collects
event reports.
SEL-5601
ACSELERATOR
®
Analytic
Assistant SEL-5601 Software
Converts SEL Compressed ASCII event
report files to oscillography.
