6.4
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Settings
View/Change Settings Over Communications Port
Append s and the specific setting name you want to view in the SHOW com-
mand to immediately jump to the setting. If s (and the setting name) is not
included, the device presents settings beginning with the first one in the device.
The SHOW command displays only the enabled settings. To display all settings,
including disabled/hidden settings, append an A to the SHOW command (e.g.,
SHOW A).
Enter Settings
The SET command (available from Access Level 2) allows you to view or
change settings. Table 6.3 lists the SET command options. The alarm contact
closes for one second when saving new settings.
Append s and the specific setting name you want to change in the SET command
to immediately jump to the setting. If s (and the setting name) is not included, the
device presents settings beginning with the first one in the device. Enter a new
setting or press <Enter> to accept the existing setting. Table 6.4 lists the editing
keystrokes.
Tab le 6. 2 SHO Command
Command Description
Access
Level
SHO s Show Device settings 1
SHO L s Show Logic settings 1
SHO G s Show Global settings 1
SHO P n s Show serial port settings, n specifies either Port F or Ports 1
through 4; defaults to the active port if not listed
1
SHO R s Show report settings such as Sequential Events Recorder
(SER) and Event Report (ER) settings
1
SHO F s Show front-panel settings 1
SHO DNP s Show DNP3 settings 1
Tab le 6. 3 SET Command
Command Description
Access
Level
SET s TERSE Set Device settings 2
SET L s TERSE Set Logic settings 2
SET G s TERSE Set Global settings 2
SET P n s TERSE Set serial port settings, depending on the device configura-
tion, n specifies either Port F or Ports 1 through 4; defaults
to the active port if not listed
2
SET R s TERSE Set SER report settings 2
SET F s TERSE Set front-panel settings 2
SET DNP s
TERSE
Set DNP3 settings 2
Tab le 6.4 SET Command Editing Keystrokes (Sheet 1 of 2)
Press Key Results
<Enter> Retains the setting and moves to the next setting
^<Enter> Returns to the previous setting
<<Enter> Returns to the previous setting category
><Enter> Moves to the next setting category
