Sel 2414 - IRIG-B Time-Code Input; Ethernet Port; Fiber-Optic Port; Cables

2.16
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Installation
Rear-Panel Connections
For connecting devices at distances over 100 feet where metallic cable is not
appropriate, SEL offers fiber-optic transceivers or the fiber-optic port. The
SEL-2800 family of transceivers provides fiber-optic links between devices for
electrical isolation and long-distance signal transmission. Contact SEL for fur-
ther information on these products.
IRIG-B Time-Code Input
The SEL-2414 accepts a demodulated IRIG-B time signal to synchronize the
internal clock with an external source. Two options for IRIG-B signal input are
given, but only one may be used at a time. IRIG-B (B01 and B02) inputs or an
SEL communications processor via fiber-optic Port 2 or serial Port 3 may be
used. See Table 6.19 for selecting the IRIG source for either Port 2 or Port 3. The
available communications processors are the SEL-2032, SEL-2030, SEL-2020,
SEL-3332, SEL-3351, and the SEL-2100 Logic Processor.
Ethernet Port
The SEL-2414 can be ordered with an optional single/dual 10/100BASE-T or
100BASE-FX fiber Ethernet communications port configuration. Connect to
Port 1 of the device using a standard RJ45 connector for the copper port and an
LC connector for the fiber-optic port.
Fiber-Optic Port
The SEL-2414 can be ordered with an optional multimode fiber-optic port which
is compatible with the SEL-2812 Fiber-Optic Transceiver. Connect to the fiber-
optic port (Port 2) using the cable shown in Table 2.17. The SEL-2414 includes a
fiber-optic port which is compatible with the SEL-2812 Fiber-Optic Transceiver
and SEL-2600 series RTD module.
Cables
Table 2.17 Communications Cables for Connecting the SEL-2414 to Other
Devices
EIA-232 Serial Ports Connect to Device SEL Cable No.
All EIA-232 ports Laptop PC, 9-pin Male (DTE) C287
EIA
-232 Port 2 (Fiber) SEL-2600 RTD Module, SEL-2812/SEL-2814
Transceiver
C807Z
EIA-232 Port 3 SEL Communications Processors and
SEL-2100 without IRIG
-B
C272A
EIA-232 Port 3 SEL Communications Processors and
SEL-2100 with IRIG
-B
C273A
