9.9
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Analyzing Events
Sequential Events Recorder (SER) Report
Sequential Events Recorder (SER) Report
The SEL-2414 SER (Sequential Events Recorder) report gives you detailed infor-
mation on device element state changes over an extended period of time. The
SER captures and time tags state changes of Device Word bits and device condi-
tions. These conditions include power up, device enable and disable, settings
changes, and SER automatic removal and reinsertion.
The SER records up to 512 state changes of up to 96 Device Word bits listed in
the SER trigger equations. SER data are stored in nonvolatile memory, ensuring
that a loss of power to the SEL-2414 will not result in lost data.
Inputs
The SER guaranteed timestamp accuracy is ±1 microsecond for physical inputs.
The Transformer Monitor samples at 250 Hz or as a function of frequency; you
select frequency tracking by installing either an optional current card or an
optional voltage card (or both).
Chatter Filtering
The SER includes a filter function to prevent overfilling of the SER buffer with
chattering information. When enabled, the device automatically deletes these
oscillating items from SER recording.
Device Settings
DID := SEL-2414
TID := DEVICE
CTR := 250
CTRN := 250
PTR := 35.00
AI301NAM:=AI301 AI301TYP:= I AI301L := 4.000 AI301H := 20.000
AI301EU := mA AI301EL := 4.000 AI301EH := 20.000 AI301LW1:= OFF
AI301LW2:= OFF AI301LAL:= OFF AI301HW1:= OFF AI301HW2:= OFF
AI301HAL:= OFF
AI302NAM:=AI302 AI302TYP:= I AI302L := 4.000 AI302H := 20.000
AI302EU := mA AI302EL := 4.000 AI302EH := 20.000 AI302LW1:= OFF
AI302LW2:= OFF AI302LAL:= OFF AI302HW1:= OFF AI302HW2:= OFF
AI302HAL:= OFF
AI303NAM:=AI303 AI303TYP:= I AI303L := 4.000 AI303H := 20.000
AI303EU := mA AI303EL := 4.000 AI303EH := 20.000 AI303LW1:= OFF
.
.
.
AI308LW2:= OFF AI308LAL:= OFF AI308HW1:= OFF AI308HW2:= OFF
AI308HAL:= OFF
Logic Settings
ELAT := N ESV := N ESC := N EMV := N
OUT101 := HALARM OR SALARM
OUT102 := RB01
OUT103 := 0
=>>
Figure 9.3 Event Report for a Current Card, a Voltage Card, an Analog Card, and
a Digital Input Card (Sheet 2 of 2)
