Analyzing Events
Event Reporting
Figure 9.3 Event Report for a Current Card, a Voltage Card, an Analog Card, and
a Digital Input Card (Sheet 1 of 2)
=>>EVE <Enter>
SEL-2414 Date: 05/30/2005 Time: 06:51:33.307
DEVICE
Serial Number=2005XXXXXXXXXXX
FID=SEL-2414-R202-V0-Z003003-D20080429 CID=0100
100 400
OUT IN IN
Currents (Amps Pri) Voltages (V Pri) 13 1 1357
IA IB IC IN VA VB VC 2 2 2468
IA IB IC IN VAB VBC VCA 2 2 2468
[1]
923.3 1588.3-2503.3 0.0 -1621 -406 2017 .. . ....
-2358.3 1970.8 414.2 0.1 1381 -2089 673 .. . ....
-921.7-1589.2 2498.3 -0.1 1620 407 -2017 .. . ....
2355.0-1971.7 -420.0 -0.1 -1383 2086 -673 .. . ....
[2]
915.8 1593.3-2499.2 0.0 -1619 -408 2019 .. . ....
-2358.3 1965.8 414.2 0.0 1383 -2088 672 .. . ....
-921.7-1599.2 2493.3 0.0 1619 408 -2022 .. . ....
2352.5-1969.2 -417.5 -0.1 -1385 2087 -671 .. . ....
[3]
918.3 1593.3-2499.2 -0.1 -1621 -411 2019 .. . ....
-2358.3 1970.8 416.7 0.0 1385 -2088 668 .. . ....
-914.2-1596.7 2493.3 0.0 1619 411 -2020 .. . ....
2357.5-1969.2 -420.0 -0.2 -1387 2086 -669 .. . ....
[4]
909.2 1595.8-2496.7 0.0 -1617 -412 2021 .. . ....
-2360.8 1963.3 414.2 0.2 1387 -2086 667 .. . ....
-914.2-1600.8 2498.3 -0.1 1616 412 -2022 .. . ....
2362.5-1966.7 -420.0 -0.1 -1388 2087 -666>.. . ....
.
.
.
[15]
883.3 1616.7-2499.2 0.0 -1600 -438 2029 .. . ....
-2367.5 1947.5 445.0 0.0 1405 -2080 645 .. . ....
-886.7-1615.0 2488.3 -0.1 1600 437 -2030 .. . ....
2364.2-1950.0 -450.0 0.0 -1406 2081 -644 .. . ....
EVENT = Trigger
TARGETS = 00000000
FREQ (Hz) = 60.0
Current Mag
IA IB IC IN
(A) 2531.9 2534.6 2541.8 0.05
Voltage Mag
VA VB VC
(V) 2130 2128 2127
Analog Input Slot 3
AI301 (mA) 0.000
AI302 (mA) 0.000
AI303 (mA) 0.000
AI304 (mA) 0.000
AI305 (mA) 0.000
AI306 (mA) 0.000
AI307 (mA) 0.000
AI308 (mA) 0.000
PARTNO=2414XXXXXXXXXXXXXXX
Global Settings
PHROT := ABC FNOM := 60
DELTA_Y := WYE
DATE_F := MDY
IN101D := 10 IN102D := 10
IN401D := 10 IN402D := 10 IN403D := 10 IN404D := 10
IN405D := 10 IN406D := 10 IN407D := 10 IN408D := 10
RSTTRGT := NA
DSABLSET:= NA
← DI Card in Slot 4
← No outputs or
inputs asserted
← Trigger row
← Analog Card in Slot 3
