5.3
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Metering and Monitoring
Metering
Table 5.3 shows the thermal meter values. To use external SEL-2600 RTDs
configure the port protocol (PROTO := RTD) and metal type (RTDxT := PT100,
NI100, NI120, or CU10, where x is 1 to 12) settings.
The thermal meter function also reports the state of connected RTDs or TCs if
any have failed. Table 5.4 shows failure messages and their meanings.
RTD/TC Metering
The thermal metering function reports the present values of the RTD and/or ther-
mocouple input temperatures when using the internal general purpose RTD/TC
card. Figure 5.2 shows the device response to the MET TEMP command.
The thermal meter function also reports the state of connected RTDs/TCs if any
have failed. Table 5.5 shows failure messages and their meanings.
Fundamental
Metering
Table 5.6 details each of the eight cycle-averaged meter data types in the
SEL-2414. These values are listed if the appropriate cards are installed and if
they are not inhibited by the type of transformer connection (see Transformer
Nameplate Application Description on page 5.11 for more information).
Table 5.3 Thermal Meter Values
Device Option Thermal Values
With External SEL-2600 Series RTD Module EXTRTD01 to EXTRTD12
With Internal RTD Option INTRTD01 to INTRTD10
With Internal RTD/TC Option INTEMP01 to INTEMP10
Table 5.4 RTD Input Status Messages
Message Status
Open RTD leads open
Short RTD leads shorted
Comm Fail Fiber-optic communications to SEL-2600 RTD module have failed
Stat Fail SEL-2600 RTD module self-test status failure
=>>MET TEMP <Enter>
SEL-2414 Date: 01/30/2002 Time: 18:55:00
DEVICE
INTEMP01 0 C PT100
INTEMP02 48 C NI100
INTEMP03 1 C NI120
INTEMP04 166 C CU10
INTEMP05 1 C J
INTEMP06 249 C K
INTEMP07 1 C T
INTEMP08 46 C E
INTEMP09 -2 C PT100
INTEMP10 -47 C NI100
=>>
Figure 5.2 Device Response to the MET TEMP Command
Table 5.5 RTD/TC Input Status Messages
Message Status
Open RTD/TC leads open
Short RTD/TC leads shorted
