Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Front-Panel Operations
Human-Machine Interface
Figure 8.13 Main Menu
Meter Menu
Select the Meter menu item on the MAIN menu to access the analog metering
data. Metered values are the 6-cycle average of the transducer values. See
METER Command (Metering Data) on page 7.18 for formatting information.
If the device contains no analog cards, then the device displays the message
shown in Figure 8.15.
MAIN
Meter
Events
Monitor
Targets
Control
Set/Show
Status
Figure 8.14 Main Menu and Meter Submenu
Figure 8.15 Device Response When No Analog Cards Are Installed
IA (A)
1.8 20.2˚
IB (A)
IC (A)
IN (A)
IG (A)
•
•
•
Frequency
METER
Fundamental
Analog Inputs
Math Variables
Remote Analogs
Meter
Events
Targets
Control
Set/Show
Status
Quit
(Meter selected)
Main
(Fundamental selected)
(Not all menu items are shown)
No Analog Input
Cards Present
To Next Page
