3.8
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Getting Started
ACSELERATOR QuickSet
Help
Various forms of ACSELERATOR QuickSet help are available, as shown in
Table 3.4. Press <F1> to open a context-sensitive help file with the appropriate
topic as the default.
ACSELERATOR QuickSet
Graphical Logic Editor
Use the ACSELERATOR QuickSet Graphical Logic Editor to create SELOGIC
settings easily by creating a logic diagram with standard logic gates.
ACSELERATOR QuickSet
Design Templates
The licensed version of ACSELERATOR QuickSet allows you to create personal-
ized templates for relay applications. Use design templates within
ACSELERATOR
QuickSet to implement such various schemes as transformer protection or fan
control. Design templates hide settings you do not want to change (e.g.,
SEL
OGIC
®
control equations), while making visible the minimum necessary
settings (e.g., timer and pickup settings) to implement the scheme. All settings
can use aliases and allow mathematical manipulation for simple end-user inter-
facing. Create design templates that include the most commonly used relay fea-
tures and settings for your application.
ACSELERATOR QuickSet design templates are stored locally on the Transformer
Monitor. This ensures that users connecting with different computers will retrieve
the correct template.
Tab le 3. 4 Hel p
Help Description
General ACSELERATOR
QuickSet
Select Help from the main menu bar
Device Editor Select SEL-5030 Editor Help from the Device Editor menu
bar
SEL-2414 Settings Select Settings Help from the Device Editor menu bar
Database manager Select Help from the bottom of the Database Manager
window
