F.8 IEC 61850 Communications
Protocol Implementation Conformance Statement: SEL-2414 Devices
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Protocol Implementation Conformance Statement:
SEL-2414 Devices
The following tables are as shown in the IEC 61850 standard, Part 8-1,
Section 24. Note that since the standard explicitly dictates which services and
functions must be implemented to achieve conformance, only the optional
services and functions are listed.
Refer to the ACSI Conformance statements in the Reference Manual for informa-
tion on the supported services.
MMS Conformance
The Manufacturing Messaging Specification (MMS) stack provides the basis for
many IEC 61850 Protocol services. Table F.8 defines the service support require-
ment and restrictions of the MMS services in the SEL-2414 series products sup-
porting IEC 61850. Generally, only those services whose implementation is not
mandatory are shown. Refer to the IEC 61850 standard Part 8-1 for more infor-
mation.
METXMDST2 MinW.instMag Minimum, Real Power X
f
,
i
METXMDST2 MinVAr.instMag Minimum, Reactive Power X
f
,
i
a
Valid data only if 10 RTD card is installed in Slot D.
b
Valid data only if internal general purpose RTD/TC card is installed in Slot D.
c
Valid data only if SEL-2600 Device is connected via fiber port.
d
See notes related to this measurand in Ta bl e I .1 in Appendix I.
e
Valid data only if 4 CT card is installed in Slot Z.
f
Valid data only if 3 CT/3 PT card is installed in Slot E.
g
Valid data only if 3 PT card is installed in Slot E.
h
Valid data only if 4 CT and 3 PT cards are installed in Slots E and Z respectively.
i
Forced to 0 if ETHERM = W.
j
Forced to 1.0 if ETHE RM = W.
Table F.5 Logical Device: MET (Metering) (Sheet 5 of 5)
Logical Nodes Measurand Comment
Table F.6 PICS for A-Profile Support
Profile Client Server Value/Comment
A1 Client/Server N Y
A2 GOOSE/GSE Management Y Y Only GOOSE, not GSSE
Management
A3 GSSE N N
A4 Time Sync N N
Table F.7 PICS for T-Profile Support
Profile Client Server Value/Comment
T1 TCP/IP N Y
T2 OSI N N
T3 GOOSE/GSE Y Y Only GOOSE, Not GSSE
T4 GSSE N N
T5 Time Sync N N
