Maximum Metering
METMDST1 MaxHz Maximum Frequency
e, f
METMDST1 MaxA.phsA.instMag Maximum, Current, A-phase
e
METMDST1 MaxA.phsB.instMag Maximum, Current, B-phase
e
METMDST1 MaxA.phsC.instMag Maximum, Current, C-phase
e
METMDST1 MaxA.neut.instMag Maximum, Current, Neutral
e
METMDST1 MaxA.res.instMag Maximum, Current, Residual
e
METMDST1 MaxA.nseq.instMag Maximum, Current, Negative Sequence
e
METXMDST2 MaxA.phsA.instMag Maximum, Current, AX-phase
f
METXMDST2 MaxA.phsB.instMag Maximum, Current, BX-phase
f
METXMDST2 MaxA.phsC.instMag Maximum, Current, CX-phase
f
METXMDST2 MaxA.res.instMag Maximum, Current, Residual X
f
METXMDST2 MaxA.nseq.instMag Maximum, Current, Negative Sequence X
f
METMDST1 MaxPhV.phsA.instMag Maximum, Voltage, A-phase-to-neutral
f, g
METMDST1 MaxPhV.phsB.instMag Maximum, Voltage, B-phase-to-neutral
f, g
METMDST1 MaxPhV.phsC.instMag Maximum, Voltage, C-phase-to-neutral
f, g
METMDST1 MaxPPV.phsAB.instMag Maximum, Voltage, A-to-B-phase
f, g
METMDST1 MaxPPV.phsBC.instMag Maximum, Voltage, B-to-C-phase
f, g
METMDST1 MaxPPV.phsCA.instMag Maximum, Voltage, C-to-A-phase
f, g
METMDST1 MaxVA.instMag Maximum, Apparent Power
h
,
i
METMDST1 MaxW.instMag Maximum, Real Power
h
,
i
METMDST1 MaxVAr.instMag Maximum, Reactive Power
h
,
i
METXMDST2 MaxVA.instMag Maximum, Apparent Power X
f
,
i
METXMDST2 MaxW.instMag Maximum, Real Power X
f
,
i
METXMDST2 MaxVAr.instMag Maximum, Reactive Power X
f
,
i
Minimum Metering
METMDST1 MinHz.instMag Minimum Frequency
e, f
METMDST1 MinA.phsA.instMag Minimum, Current, A-phase
e
METMDST1 MinA.phsB.instMag Minimum, Current, B-phase
e
METMDST1 MinA.phsC.instMag Minimum, Current, C-phase
e
METMDST1 MinA.neut.instMag Minimum, Current, Neutral
e
METMDST1 MinA.res.instMag Minimum, Current, Residual
e
METMDST1 MinA.nseq.instMag Minimum, Current, Negative Sequence
e
METXMDST2 MinA.phsA.instMag Minimum, Current, AX-phase
f
METXMDST2 MinA.phsB.instMag Minimum, Current, BX-phase
f
METXMDST2 MinA.phsC.instMag Minimum, Current, CX-phase
f
METXMDST2 MinA.res.instMag Minimum, Current, Residual X
f
METXMDST2 MinA.nseq.instMag Minimum, Current, Negative Sequence X
f
METMDST1 MinPhV.phsA.instMag Minimum, Voltage, A-phase-to-neutral
f, g
METMDST1 MinPhV.phsB.instMag Minimum, Voltage, B-phase-to-neutral
f, g
METMDST1 MinPhV.phsC.instMag Minimum, Voltage, C-phase-to-neutral
f, g
METMDST1 MinPPV.phsAB.instMag Minimum, Voltage, A-to-B-phase
f, g
METMDST1 MinPPV.phsBC.instMag Minimum, Voltage, B-to-C-phase
f, g
METMDST1 MinPPV.phsCA.instMag Minimum, Voltage, C-to-A-phase
f, g
METMDST1 MinVA.instMag Minimum, Apparent Power
h
,
i
METMDST1 MinW.instMag Minimum, Real Power
h
,
i
METMDST1 MinVAr.instMag Minimum, Reactive Power
h
,
i
METXMDST2 MinVA.instMag Minimum, Apparent Power X
f
,
i
Table F.5 Logical Device: MET (Metering) (Sheet 4 of 5)
Logical Nodes Measurand Comment
