F.6 IEC 61850 Communications
Logical Nodes
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
METXMMXU1 VA.phsA.instMag Instantaneous, Apparent Power A
f
,
i
METXMMXU1 VA.phsB.instMag Instantaneous, Apparent Power B
f
,
i
METXMMXU1 VA.phsC.instMag Instantaneous, Apparent Power C
f
,
i
METXMMXU1 TotPF.instMag Instantaneous, Three-Phase Power Factor
f
,
j
METXMMXU1 PhAPF.instMag Instantaneous, Power Factor A
f
,
j
METXMMXU1 PhBPF.instMag Instantaneous, Power Factor B
f
,
j
METXMMXU1 PhCPF.instMag Instantaneous, Power Factor C
f
,
j
Demand Metering
METMDST1 DmdA.phsA.instMag Demand, Phase A Current
e
METMDST1 DmdA.phsB.instMag Demand, Phase B Current
e
METMDST1 DmdA.phsC.instMag Demand, Phase C Current
e
METMDST1 DmdA.neut.instMag Demand, Current, Neutral
e
METMDST1 DmdA.res.instMag Demand, Current, Residual
e
METMDST1 DmdA.nseq.instMag Demand, Current, Negative Sequence
e
METXMDST2 DmdA.phsA.instMag Demand, Current, Phase AX
f
METXMDST2 DmdA.phsB.instMag Demand, Current, Phase BX
f
METXMDST2 DmdA.phsC.instMag Demand, Current, Phase CX
f
METXMDST2 DmdA.res.instMag Demand, Current, Residual X
f
METXMDST2 DmdA.nseq.instMag Demand, Current, Negative Sequence X
f
Peak Demand Metering
METMDST1 PkDmdA.phsA.instMag Peak Demand, Current, Phase A
e
METMDST1 PkDmdA.phsB.instMag Peak Demand, Current, Phase B
e
METMDST1 PkDmdA.phsC.instMag Peak Demand, Current, Phase C
e
METMDST1 PkDmdA.neut.instMag Peak Demand, Current, Neutral
e
METMDST1 PkDmdA.res.instMag Peak Demand, Current, Residual
e
METMDST1 PkDmdA.nseq.instMag Peak Demand, Current, Negative Sequence
e
METXMDST2 PkDmdA.phsA.instMag Peak Demand, Current, Phase AX
f
METXMDST2 PkDmdA.phsB.instMag Peak Demand, Current, Phase BX
f
METXMDST2 PkDmdA.phsC.instMag Peak Demand, Current, Phase CX
f
METXMDST2 PkDmdA.res.instMag Peak Demand, Current, Residual X
f
METXMDST2 PkDmdA.nseq.instMag Peak Demand, Current, Negative Sequence X
f
Energy Metering
METMDST1 SupWh.instMag Energy, Real (MWh), Default direction: energy flow towards
busbar.
h
,
i
METMDST1 SupVArh.instMag Energy, Reactive (MVArh)
h
,
i
METMDST1 SupVAh.instMag Energy, Apparent (MVAh)
h
,
i
METMDST1 DmdWh.instMag Energy, Real (MWh), Default direction: energy flow from busbar
away.
h
,
i
METMDST1 DmdVArh.instMag Energy, Reactive (MVArh)
h
,
i
METMDST1 DmdVAh.instMag Energy, Apparent (MVAh)
h
,
i
METXMDST2 SupWh.instMag Energy, Real (MWh)
f
,
i
METXMDST2 DmdWh.instMag Energy, Real (MWh)
f
,
i
METXMDST2 SupVAh.instMag Energy, Apparent (MVAh)
f
,
i
METXMDST2 SupVArh.instMag Energy, Reactive (MVArh)
f
,
i
METXMDST2 DmdVArh.instMag Energy, Reactive (MVArh)
f
,
i
METXMDST2 DmdVAh.instMag Energy, Apparent (MVAh)
f
,
i
Table F.5 Logical Device: MET (Metering) (Sheet 3 of 5)
Logical Nodes Measurand Comment
