SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Introduction and Specifications
Features
Features
Physical
Monitoring
Automation and
Control
Standard
Two isolated dry inputs and three outputs (two Form A and one Form C)
Human-Machine-Interface (HMI)
One front serial port
One rear serial port (compatible with SEL
-2810, SEL-2814, SEL-3010, . . .)
IRIG
-B input
Optional
Analog inputs and outputs
Digital inputs and outputs
Voltages (wye or open-delta)
Currents
RTDs
Thermocouples
EIA
-232 or EIA-485 card
One or two (failover) Ethernet ports
Fiber-optic port (compatible with SEL
-2600A, SEL-2600D, SEL-2812)
Standard
Thermal Model (IEEE C57.91-1995)
➤ Hot-Spot Temperature
➤ Loss-of-Life
➤ Aging Acceleration
Through-Fault
Analog Signal Profile (e.g., Ambient, Hot-Spot and Top-Oil Temperatures; Pressure; Oil
Water Content; etc.)
Sequential Event Report (SER)
Event Report
Standard
Programmable Boolean operators (such as AND, OR, and NOT)
Programmable math operators (add, subtract, multiply, and divide)
Programmable logic functions (timers, counters, and latches)
Programmable analog comparisons
Programmable rising and falling edge trigger
Digital output logic to assign logic outputs to digital outputs
Remote control to close digital outputs and reset latched indicators from remote locations
