Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Settings
Global Settings (SET G Command)
T
Data Reset
The RSTTRGT setting resets the front-panel LEDs, provided all LED initiate
conditions were cleared. Table 6.18 shows the settings prompt, setting range, and
factory default settings.
Time Synchronization
Source
This setting is only available when the Device configuration includes a fiber-
optic port. Use the Time Synchronization Source Setting to declare the source of
the IRIG input. The SEL-2414 accepts IRIG input from either Port 2 or Port 3. If
the IRIG source is Port 3, select IRIG1 as the setting. If the IRIG source is Port 2
(fiber-optic port), select IRIG2 as the setting.
Access Control
The DSABLSET setting defines conditions for disabling all setting changes from
the front-panel interface. To disable setting changes from the front-panel inter-
face, assign, for example, a contact input (e.g., DSABLSET := IN402) to the
DSABLSET setting. When Device Word bit DSABLSET asserts, you can view
the device settings from the front-panel interface, but you can only change set-
tings using serial port commands. Table 6.20 shows the settings prompt, setting
range, and factory default settings.
Voltage Ratio
Correction Factor
Table 6.17 General Global Settings
Setting Prompt Setting Range
Setting Name :=
Factory Defaul t
IN301 Debounce AC, 0–65000 ms IN301D := 10
IN302 Debounce AC, 0–65000 ms IN302D := 10
IN303 Debounce AC, 0–65000 ms IN303D := 10
IN304 Debounce AC, 0–65000 ms IN304D := 10
IN305 Debounce AC, 0–65000 ms IN305D := 10
IN306 Debounce AC, 0–65000 ms IN306D := 10
IN307 Debounce AC, 0–65000 ms IN307D := 10
IN308 Debounce AC, 0–65000 ms IN308D := 10
Table 6.18 Target Reset Setting
Setting Prompt Setting Range Setting Name := Factory Default
Target Reset SV RSTTRGT := NA
Table 6.19 Time Synchronization Source Setting
Setting Prompt Setting Range Setting Name := Factory Default
IRIG Time Source IRIG1, IRIG2 TIME_SRC := IRIG1
Table 6.20 Setting Change Disable Setting
Setting Prompt Setting Range Setting Name := Factory Default
Disable FP Settings Change SV DSABLSET := NA
Table 6.21 Voltage Ratio Correction Factor
Setting Prompt Setting Range Setting Name := Factory Default
VARCF 0.5 to 1.5
VBRCF 0.5 to 1.5
VCRCF 0.5 to 1.5
