Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Section 2
Instruction Manual
Installation
Overview
The first steps in applying the SEL-2414 Transformer Monitor are installing and
connecting the device. This section describes common installation features and
requirements and I/O options. To install and connect the device safely and effec-
tively, you must be familiar with device configuration features and options. You
should carefully plan the placement, cable connections, and communication. This
section contains drawings of typical ac and dc connections to the SEL-2414. Use
these drawings as a starting point for planning your particular application.
