Sel 2414 - Modbus Register Map

E.7
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Modbus Communications
Modbus Register Map
Modbus Register Map
Table E.15 Modbus Register Map (Sheet 1 of 25)
Address in
Decimal
Address
in Hex
Function
Code
Supported
Conversion Min Max Default Name/Enums Units
Device ID
0–21 0–15 03h, 04h 12 FID Char (1–44)
22–43 16–2B 03h, 04h 12 BFID Char (1–44)
44–45 2C–2D 03h, 04h 12 CID Char (1–4)
46–53 2E–35 03h, 04h 12 DEVID Char (1–16)
54 36 03h, 04h 1 DEVCODE
55–64 37–40 03h, 04h 12 Part Number Char (1–20)
65–67 41–43 03h, 04h 12 Config (1–6)
68–149 44–95 03h, 04h 5 8000 8000 8000 Reserved = 8000 Hex
Device Status
150 96 03h, 04h 0 0 1 IA Status 0-OK, 1-WARN
151 97 03h, 04h 0 0 1 IB Status 0-OK, 1-WARN
152 98 03h, 04h 0 0 1 IC Status 0-OK, 1-WARN
153 99 03h, 04h 0 0 1 IN Status 0-OK, 1-WARN
154 9A 03h, 04h 0 0 1 VA Status 0-OK, 1-WARN
155 9B 03h, 04h 0 0 1 VB Status 0-OK, 1-WARN
156 9C 03h, 04h 0 0 1 VC Status 0-OK, 1-WARN
157 9D 03h, 04h 0 8000 8000 8000 Reserved = 8000 Hex
158 9E 03h, 04h 0 0 1 FPGA Status 0-OK, 2-FAIL
159 9F 03h, 04h 0 0 1 GPSB Status 0-OK, 2-FAIL
160 A0 03h, 04h 0 0 1 HMI Status
0-OK, 1-WARN
161 A1 03h, 04h 0 0 1 RAM Status 0-OK, 2-FAIL
162 A2 03h, 04h 0 0 1 ROM Status 0-OK, 2-FAIL
163 A3 03h, 04h 0 0 1 CR_RAM Status
0-OK, 2-FAIL
164 A4 03h, 04h 0 0 1 NON_VOL Status
0-OK, 2-FAIL
165 A5 03h, 04h 0 0 1 CLK_BAT Status
0-OK, 1-WARN
166 A6 03h, 04h 0 0 1 CLOCK Status
0-OK, 1-WARN
167 A7 03h, 04h 0 0 1 CARD C Status
0-OK, 2-FAIL
168 A8 03h, 04h 0 0 1 CARD D Status
0-OK, 2-FAIL
169 A9 03h, 04h 0 0 1 CARD E Status
0-OK, 2-FAIL
170 AA 03h, 04h 0 0 1 CARD Z Status
0-OK, 2-FAIL
