E.8
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Modbus Communications
Modbus Register Map
171 AB 03h, 04h 0 0 1 ENABLED
0-Enabled, 2-Disabled
172 AC 03h, 04h 0 0 1 IAX Status 0-OK, 1-Warn
173 AD 03h, 04h 0 0 1 IBX Status 0-OK, 1-Warn
174 AE 03h, 04h 0 0 1 ICX Status 0-OK, 1-Warn
175 AF 03h, 05h 0 0 1 INTRTD or INTEMP Status
0-OK, 2-Fail
176 B0 03h, 04h 0 0 1 EXTRTD Status
0-OK, 2-Fail
177 B1 03h, 04h 0 0 1 CID FILE Status
0-OK, 2-Fail
178 B2 03h, 04h 0 0 1 3.3 V Status
0-OK, 1-Warn, 2-Fail
179 B3 03h, 04h 0 0 1 5.0 V Status
0-OK, 1-Warn, 2-Fail
180 B4 03h, 04h 0 0 1 2.5 V Status
0-OK, 1-Warn, 2-Fail
181 B5 03h, 04h 0 0 1 3.75 V Status
0-OK, 1-Warn, 2-Fail
182 B6 03h, 04h 0 0 1 –1.25 V Status
0-OK, 1-Warn, 2-Fail
183 B7 03h, 04h 0 0 1 –5.0 V Status
0-OK, 1-Warn, 2-Fail
184 B8 03h, 04h 0 0 1 0.9 V Status
0-OK, 1-Warn, 2-Fail
185 B9 03h, 04h 0 0 1 1.2 V Status
0-OK, 1-Warn, 2-Fail
186 BA 03h, 04h 0 0 1 1.5 V Status
0-OK, 1-Warn, 2-Fail
187 BB 03h, 04h 0 0 1 1.8 V Status
0-OK, 1-Warn, 2-Fail
188–199 BC–C7 03h, 04h 5 8000 8000 8000 Reserved = 8000 Hex
Current Data
200 C8 03h, 04h 1 0 65535 0 IA Magnitude A
201 C9 03h, 04h 7 –1800 1800 0 IA Angle Deg
202 CA 03h, 04h 1 0 65535 0 IB Magnitude A
203 CB 03h, 04h 7 –1800 1800 0 IB Angle Deg
204 CC 03h, 04h 1 0 65535 0 IC Magnitude A
205 CD 03h, 04h 7 –1800 1800 0 IC Angle Deg
206 CE 03h, 04h 1 0 65535 0 IN Magnitude A
207 CF 03h, 04h 7 –1800 1800 0 IN Angle deg
208 D0 03h, 04h 1 0 65535 0 IG Magnitude A
209 D1 03h, 04h 7 –1800 1800 0 IG Angle deg
210 D2 03h, 04h 1 0 65535 0 3I2 Magnitude A
211 D3 03h, 04h 1 0 65535 0 IAX Magnitude A
Table E.15 Modbus Register Map (Sheet 2 of 25)
Address in
Decimal
Address
in Hex
Function
Code
Supported
Conversion Min Max Default Name/Enums Units
