Sel 2414 - Page 285

E.9
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Modbus Communications
Modbus Register Map
212 D4 03h, 04h 7 –1800 1800 0 IAX Angle deg
213 D5 03h, 04h 1 0 65535 0 IBX Magnitude A
214 D6 03h, 04h 7 –1800 1800 0 IBX Angle deg
215 D7 03h, 04h 1 0 65535 0 ICX Magnitude A
216 D8 03h, 04h 7 –1800 1800 0 ICX Angle deg
217 D9 03h, 04h 1 0 65535 0 IGX Magnitude A
218 DA 03h, 04h 7 –1800 1800 0 IGX Angle deg
219 DB 03h, 04h 1 0 65535 0 312X Magnitude A
220–249 DC–F9 03h, 04h 5 8000 8000 8000 Reserved = 8000 Hex
Voltage Data
250 FA 03h, 04h 13 0 5200000 0 VAB Magnitude—UW
a
V
251 FB 03h, 04h 0 VAB Magnitude—LW
b
V
252 FC 03h, 04h 7 –1800 1800 0 VAB Angle deg
253 FD 03h, 04h 13 0 5200000 0 VBC Magnitude—UW V
254 FE 03h, 04h 0 VBC Magnitude—LW V
255 FF 03h, 04h 7 –1800 1800 0 VBC Angle deg
256 100 03h, 04h 13 0 5200000 0 VCA Magnitude—UW V
257 101 03h, 04h 0 VCA Magnitude—LW V
258 102 03h, 04h 7 –1800 1800 0 VCA Angle deg
259 103 03h, 04h 13 0 5200000 0 VAN Magnitude—UW V
260 104 03h, 04h 0 VAN Magnitude—LW V
261 105 03h, 04h 7 –1800 1800 0 VAN Angle deg
262 106 03h, 04h 13 0 5200000 0 VBN Magnitude—UW V
263 107 03h, 04h 0 VBN Magnitude—LW V
264 108 03h, 04h 7 –1800 1800 0 VBN Angle deg
265 109 03h, 04h 13 0 5200000 0 VCN Magnitude—UW V
266 10A 03h, 04h 0 VCN Magnitude—LW V
267 10B 03h, 04h 7 –1800 1800 0 VCN Angle deg
268 10C 03h, 04h 13 0 5200000 0 VG Magnitude—UW V
269 10D 03h, 04h 0 VG Magnitude—LW V
270 10E 03h, 04h 7 –1800 1800 0 VG Angle deg
271 10F 03h, 04h 13 0 5200000 0 3V2 Magnitude—UW V
272 110 03h, 04h 0 3V2 Magnitude—LW V
273–299 111–12B 03h, 04h 5 8000 8000 0 Reserved = 8000 Hex
Power Data
c
300 12C 03h, 04h 13 –200000000 200000000 0 Phase A Real Power—UW kW
301 12D 03h, 04h Phase A Real Power—LW kW
302 12E 03h, 04h 13 –200000000 200000000 0 Phase A Reactive Power—
UW
kVAR
Table E.15 Modbus Register Map (Sheet 3 of 25)
Address in
Decimal
Address
in Hex
Function
Code
Supported
Conversion Min Max Default Name/Enums Units
