E.10

SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214

Modbus Communications

Modbus Register Map

303 12F 03h, 04h 0 Phase A Reactive Power—

kVAR

304 130 03h, 04h 13 –200000000 200000000 0 Phase A Apparent Power—

kVA

305 131 03h, 04h 0 Phase A Apparent Power—

kVA

306 132 03h, 04h 8 –100 100 0 Phase A Power Factor

307 133 03h, 04h 13 –200000000 200000000 0 Phase B Real Power—UW kW

308 134 03h, 04h 0 Phase B Real Power—LW kW

309 135 03h, 04h 13 –200000000 200000000 0 Phase B Reactive Power—

kVAR

310 136 03h, 04h 0 Phase B Reactive Power—

kVAR

311 137 03h, 04h 13 –200000000 200000000 0 Phase B Apparent Power—

kVA

312 138 03h, 04h 0 Phase B Apparent Power—

kVA

313 139 03h, 04h 8 –100 100 0 Phase B Power Factor

314 13A 03h, 04h 13 –200000000 200000000 0 Phase C Real Power—UW kW

315 13B 03h, 04h 0 Phase C Real Power—LW kW

316 13C 03h, 04h 13 –200000000 200000000 0 Phase C Reactive Power—

kVAR

317 13D 03h, 04h 0 Phase C Reactive Power—

kVAR

318 13E 03h, 04h 13 –200000000 200000000 0 Phase C Apparent Power—

kVA

319 13F 03h, 04h 0 Phase C Apparent Power—

kVA

320 140 03h, 04h 8 –100 100 0 Phase C Power Factor

321 141 03h, 04h 13 –200000000 200000000 0 Three-Phase Real Power—

322 142 03h, 04h 0 Three-Phase Real Power—

323 143 03h, 04h 13 –200000000 200000000 0 Three-Phase Reactive

Power—UW

kVAR

324 144 03h, 04h 0 Three-Phase Reactive

Power—LW

kVAR

325 145 03h, 04h 13 –200000000 200000000 0 Three-Phase Apparent

Power—UW

kVA

326 146 03h, 04h 0 Three-Phase Apparent

Power—LW

kVA

327 147 03h, 04h 8 –100 100 0 Three-Phase Power Factor

328 148 03h, 04h 13 –200000000 200000000 0 Phase A Real PowerX

—

329 149 03h, 04h 0 Phase A Real PowerX

—

Table E.15 Modbus Register Map (Sheet 4 of 25)
