E.11
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Modbus Communications
Modbus Register Map
330 14A 03h, 04h 13 –200000000 200000000 0 Phase A Reactive
PowerX
d
—UW
kVAR
331 14B 03h, 04h 0 Phase A Reactive
PowerX
d
—LW
kVAR
332 14C 03h, 04h 13 –200000000 200000000 0 Phase A Apparent
PowerX
d
—UW
kVA
333 14D 03h, 04h 0 Phase A Apparent
PowerX
d
—LW
kVA
334 14E 03h, 04h 8 –100 100 0 Phase A PowerX
d
Factor
335 14F 03h, 04h 13 –200000000 200000000 0 Phase B Real PowerX
d
—
UW
kW
336 150 03h, 04h 0 Phase B Real PowerX
d
—
LW
kW
337 151 03h, 04h 13 –200000000 200000000 0 Phase B Reactive
PowerX
d
—UW
kVAR
338 152 03h, 04h 0 Phase B Reactive
PowerX
d
—LW
kVAR
339 153 03h, 04h 13 –200000000 200000000 0 Phase B Apparent
PowerX
d
—UW
kVA
340 154 03h, 04h 0 Phase B Apparent
PowerX
d
—LW
kVA
341 155 03h, 04h 8 –100 100 0 Phase B PowerX
d
Factor
342 156 03h, 04h 13 –200000000 200000000 0 Phase C Real PowerX
d
—
UW
kW
343 157 03h, 04h 0 Phase C Real PowerX
d
—
LW
kW
344 158 03h, 04h 13 –200000000 200000000 0 Phase C Reactive
PowerX
d
—UW
kVAR
345 159 03h, 04h 0 Phase C Reactive
PowerX
d
—LW
kVAR
346 15A 03h, 04h 13 –200000000 200000000 0 Phase C Apparent
PowerX
d
—UW
kVA
347 15B 03h, 04h 0 Phase C Apparent
PowerX
d
—LW
kVA
348 15C 03h, 04h 8 –100 100 0 Phase C PowerX
d
Factor
349 15D 03h, 04h 13 –200000000 200000000 0 Three-Phase Real
PowerX
d
—UW
kW
350 15E 03h, 04h 0 Three-Phase Real
PowerX
d
—LW
kW
351 15F 03h, 04h 13 –200000000 200000000 0 Three-Phase Reactive
PowerX
d
—UW
kVAR
352 160 03h, 04h 0 Three-Phase Reactive
PowerX
d
—LW
kVAR
353 161 03h, 04h 13 –200000000 200000000 0 Three-Phase Apparent
PowerX
d
—UW
kVA
354 162 03h, 04h 0 Three-Phase Apparent
PowerX
d
—LW
kVA
Table E.15 Modbus Register Map (Sheet 5 of 25)
