E.12
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Modbus Communications
Modbus Register Map
355 163 03h, 04h 8 –100 100 0 Three-Phase PowerX
d
Factor
356–379 164–17B 03h, 04h 5 8000 8000 8000 Reserved = 8000 Hex
Frequency
380 17C 03h, 04h 7 440 660 600 Frequency Hz
381–399 17D–18F 03h, 04h 5 8000 8000 8000 Reserved = 8000 Hex
Historical Data
400 190 03h, 04h 1 0 30 0 Number of Event Records
401 191 03h, 04h,
06h, 10h
1 0 30 0 Event Summary Record
Selected
402 192 03h, 04h 3 0 5999 0 Event Time ss.ss
403 193 03h, 04h 1 0 59 0 Event Time mm
404 194 03h, 04h 1 0 23 0 Event Time hh
405 195 03h, 04h 1 1 31 1 Event Day DD
406 196 03h, 04h 1 1 12 1 Event Month MM
407 197 03h, 04h 1 0 2999 0 Event Year YYYY
408 198 03h, 04h 10 0 2 0 Event Type
0 = No Event
1 = Trigger
2 = ER Trigger
409 199 03h, 04h 3 4400 6600 Event Frequency Hz
410 19A 03h, 04h 1 0 65535 0 Event IA A
411 19B 03h, 04h 1 0 65535 0 Event IB A
412 19C 03h, 04h 1 0 65535 0 Event IC A
413 19D 03h, 04h 1 0 65535 0 Event IN A
414 19E 03h, 04h 13 0 5200000 0 Event VAB/VAN—UW V
415 19F 03h, 04h 0 Event VAB/VAN—LW V
416 1A0 03h, 04h 13 0 5200000 0 Event VBC/VBN—UW V
417 1A1 03h, 04h 0 Event VBC/VBN—LW V
418 1A2 03h, 04h 13 0 5200000 0 Event VCA/VCN—UW V
419 1A3 03h, 04h 0 Event VCA/VCN—LW V
420 1A4 03h, 04h 10 0 1 0 0 = Delta, 1 = Wye
421 1A5 03h, 04h 16 –2147483648 +2147483647 0 Event AI301—UW EU
e
422 1A6 03h, 04h 0 Event AI301—LW EU
423 1A7 03h, 04h 16 –2147483648 +2147483647 0 Event AI302—UW EU
424 1A8 03h, 04h 0 Event AI302—LW EU
425 1A9 03h, 04h 16 –2147483648 +2147483647 0 Event AI303—UW EU
426 1AA 03h, 04h 0 Event AI303—LW EU
427 1AB 03h, 04h 16 –2147483648 +2147483647 0 Event AI304—UW EU
428 1AC 03h, 04h 0 Event AI304—LW EU
429 1AD 03h, 04h 16 –2147483648 +2147483647 0 Event AI305—UW EU
Table E.15 Modbus Register Map (Sheet 6 of 25)
Address in
Decimal
Address
in Hex
Function
Code
Supported
Conversion Min Max Default Name/Enums Units
