Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Modbus Communications
Modbus Register Map
430 1AE 03h, 04h 0 Event AI305—LW EU
431 1AF 03h, 04h 16 –2147483648 +2147483647 0 Event AI306—UW EU
432 1B0 03h, 04h 0 Event AI306—LW EU
433 1B1 03h, 04h 16 –2147483648 +2147483647 0 Event AI307—UW EU
434 1B2 03h, 04h 0 Event AI307—LW EU
435 1B3 03h, 04h 16 –2147483648 +2147483647 0 Event AI308—UW EU
436 1B4 03h, 04h 0 Event AI308—LW EU
437 1B5 03h, 04h 16 –2147483648 +2147483647 0 Event AI401—UW EU
438 1B6 03h, 04h 0 Event AI401—LW EU
439 1B7 03h, 04h 16 –2147483648 +2147483647 0 Event AI402—UW EU
440 1B8 03h, 04h 0 Event AI402—LW EU
441 1B9 03h, 04h 16 –2147483648 +2147483647 0 Event AI403—UW EU
442 1BA 03h, 04h 0 Event AI403—LW EU
443 1BB 03h, 04h 16 –2147483648 +2147483647 0 Event AI404—UW EU
444 1BC 03h, 04h 0 Event AI404—LW EU
445 1BD 03h, 04h 16 –2147483648 +2147483647 0 Event AI405—UW EU
446 1BE 03h, 04h 0 Event AI405—LW EU
447 1BF 03h, 04h 16 –2147483648 +2147483647 0 Event AI406—UW EU
448 1C0 03h, 04h 0 Event AI406—LW EU
449 1C1 03h, 04h 16 –2147483648 +2147483647 0 Event AI407—UW EU
450 1C2 03h, 04h 0 Event AI407—LW EU
451 1C3 03h, 04h 16 –2147483648 +2147483647 0 Event AI408—UW EU
452 1C4 03h, 04h 0 Event AI408—LW EU
453 1C5 03h, 04h 16 –2147483648 +2147483647 0 Event AI501—UW EU
454 1C6 03h, 04h 0 Event AI501—LW EU
455 1C7 03h, 04h 16 –2147483648 +2147483647 0 Event AI502—UW EU
456 1C8 03h, 04h 0 Event AI502—LW EU
457 1C9 03h, 04h 16 –2147483648 +2147483647 0 Event AI503—UW EU
458 1CA 03h, 04h 0 Event AI503—LW EU
459 1CB 03h, 04h 16 –2147483648 +2147483647 0 Event AI504—UW EU
460 1CC 03h, 04h 0 Event AI504—LW EU
461 1CD 03h, 04h 16 –2147483648 +2147483647 0 Event AI505—UW EU
462 1CE 03h, 04h 0 Event AI505—LW EU
463 1CF 03h, 04h 16 –2147483648 +2147483647 0 Event AI506—UW EU
464 1D0 03h, 04h 0 Event AI506—LW EU
465 1D1 03h, 04h 16 –2147483648 +2147483647 0 Event AI507—UW EU
466 1D2 03h, 04h 0 Event AI507—LW EU
467 1D3 03h, 04h 16 –2147483648 +2147483647 0 Event AI508—UW EU
468 1D4 03h, 04h 0 Event AI508—LW EU
469 1D5 03h, 04h 16 –2147483648 +2147483647 0 Event AI601—UW EU
Table E.15 Modbus Register Map (Sheet 7 of 25)
Address in
Decimal
Address
in Hex
Function
Code
Supported
Conversion Min Max Default Name/Enums Units
To Next Page
