D.9
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
DNP3 Communications
DNP3 in the SEL-2414
Reference Data Map
Table D.6 shows the SEL-2414 reference data map. The reference map shows the
data available to a DNP3 master. You can use the default map or the custom
DNP3 mapping functions of the SEL-2414 to retrieve only the points required by
your application.
NOTE: Dead-band changes via
Object 34 are stored in nonvolatile
memory. Make sure to reissue the
Object 34 dead bands after a warm
(STA C) or cold start (power cycle).
The SEL-2414 scales analog values by settings or fixed scaling. Analog dead
bands for event reporting use settings, or ANADBM if you have not specified a
setting.
Tab l e D.6 DN P3 Refe r e nc e D ata M ap
a
(Sheet 1 of 3)
Object Labels Description
Binary Inputs
01, 02 STFAIL Device Diagnostic Failure
01, 02 STWARN Device Diagnostic Warning
01, 02 STSET Device Settings Changed Warning
01, 02 Enabled–T06_LED Device Word Elements, Row 0, Targets (see Table H.1)
01, 02 PB01_LED to PB04BLED Device Word Elements, Row 1 to Row 123 (see Table H.1)
01, 02 PFL Power Factor Leading for Three-Phase Currents
b
01, 02 PFLX Power Factor Leading for Three-Phase Currents
c
01, 02 PFL_x Power Factor Leading for Single-Phase Currents (x = A, B, and C)
b
01, 02 PFL_xX Power Factor Leading for Single-Phase Currents (x = A, B, and C)
c
Binary Outputs
10, 12 RBxx Remote Bits (RB01 to RB32)
Counters
20, 22 SCxx SELOGIC
®
Counter Values (SC01 to SC32)
Analog Inputs
General Analog Inputs
30, 32, 34 AI30x Analog Inputs (AI301 to AI308)—Slot C
30, 32, 34 AI40x Analog Inputs (AI401 to AI408)—Slot D
30, 32, 34 AI50x Analog Inputs (AI501 to AI508)—Slot E
30, 32, 34 AI60x Analog Inputs (AI601 to AI608)—Slot Z
30, 32, 34 RAxxx Remote Analogs (RA001 to RA128)
30, 32, 34 INTRTDxx Internal RTDs (INTRTD01–INTRTD10)—Slot D
d
30, 32, 34 EXTRTDxx External RTDs (EXRTD01–EXRTD12)
e
30, 32, 34 INTEMPxx Internal RTDs/TC from general purpose temp card (INTEMP01–
INTEMP10)—Slot D only
f
30, 32, 34 MVxx Math Variables (MV01 to MV32)
Fundamental Metering
30, 32, 34 FREQ Instantaneous, Frequency
c,
g
30, 32, 34 Vx_MAG Instantaneous, Voltage Magnitude (x = A, B, C and G)
c,
h
30, 32, 34 Vx_ANG Instantaneous, Voltage Angle (x = A, B, C and G)
c, h
30, 32, 34 3V2 Instantaneous, Negative-Sequence Voltage
c, h
30, 32, 34 Ix_MAG Instantaneous, Current Magnitude (x = A, B, C, N and G)
g
30, 32, 34 Ix_ANG Instantaneous, Current Angle (x = A, B, C, N and G)
g
30, 32, 34 P Instantaneous, Three-Phase Real Power
b
30, 32, 34 Px Instantaneous, Real Power (x = A, B and C)
b
30, 32, 34 Q Instantaneous, Three-Phase Reactive Power
b
30, 32, 34 Qx Instantaneous, Reactive Power (x = A, B and C)
b
30, 32, 34 S Instantaneous, Three-Phase Apparent Power
b
30, 32, 34 Sx Instantaneous, Apparent Power (x = A, B and C)
b
30, 32, 34 PF Instantaneous, Three-Phase Power Factor
b
30, 32, 34 PFx Instantaneous, Power Factor (x = A, B and C)
b
