D.10
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
DNP3 Communications
DNP3 in the SEL-2414
30, 32, 34 3I2 Instantaneous, Current, Negative-Sequence
g
30, 32, 34 IxX_MAG Instantaneous, Current Magnitude (x = A, B, C and G)
c
30, 32, 34 IxX_ANG Instantaneous, Current Angle (x = A, B, C and G)
c
30, 32, 34 PX Instantaneous, Three-Phase Real Power
c
30, 32, 34 PxX Instantaneous, Real Power (x = A, B and C)
c
30, 32, 34 QX Instantaneous, Three-Phase Reactive Power
c
30, 32, 34 QxX Instantaneous, Reactive Power (x = A, B and C)
c
30, 32, 34 SX Instantaneous, Three-Phase Apparent Power
c
30, 32, 34 SxX Instantaneous, Apparent Power (x = A, B and C)
c
30, 32, 34 PFX Instantaneous, Three-Phase Power Factor
c
30, 32, 34 PFxX Instantaneous, Power Factor (x = A, B and C)
c
30, 32, 34 3I2X Instantaneous, Current, Negative-Sequence
c
Demand Metering
30, 32, 34 IxD Demand, Current Magnitude (x = A, B, C, N and G)
g
30, 32, 34 3I2D Demand, Current, Negative Sequence
g
30, 32, 34 IxXD Demand, Current Magnitude X (x = A, B, C and G)
c
30, 32, 34 3I2XD Demand, Current, Negative Sequence X
c
Peak Demand Metering
30, 32, 34 IxPD Peak Demand, Current Magnitude (x = A, B, C, N and G)
g
30, 32, 34 3I2PD Peak Demand, Current, Negative Sequence
g
30, 32, 34 IxXPD Peak Demand, Current Magnitude X (x = A, B, C and G)
c
30, 32, 34 3I2XPD Peak Demand, Current, Negative Sequence X
c
Energy Metering
30, 32, 34 MWH3PI Energy, Real (MWh), In: energy flow towards busbar
b
30, 32, 34 MQH3PI Energy, Reactive (MVArh) In
b
30, 32, 34 MSH3PI Energy, Apparent (MVAh) In
b
30, 32, 34 MWH3PO Energy, Real (MWh), Out: energy flow from busbar away
b
30, 32, 34 MQH3PO Energy, Reactive (MVArh) Out
b
30, 32, 34 MSH3PO Energy, Apparent (MVAh) Out
b
30, 32, 34 MWH3PIX Energy, Real (MWh) In
c
30, 32, 34 MQH3PIX Energy, Reactive X (MVArh) In
c
30, 32, 34 MSH3PIX Energy, Apparent X (MVAh) In
c
30, 32, 34 MWH3POX Energy, Real X (MWh) Out
c
30, 32, 34 MQH3POX Energy, Reactive X (MVArh) Out
c
30, 32, 34 MSH3POX Energy, Apparent X (MVAh) Out
c
Maximum Metering
30, 32, 34 FREQMX Maximum Frequency
c, g
30, 32, 34 VxMX Maximum, Voltage (x = A, B and C)
c, h
30, 32, 34 VxxMX Maximum, Voltage (xx = AB, BC and CA)
c, h
30, 32, 34 IxMX Maximum, Current Magnitude (x = A, B, C, N and G)
g
30, 32, 34 3I2MX Maximum, Current, Negative Sequence
g
30, 32, 34 KS3PMX Maximum, Apparent Power
b
30, 32, 34 KW3PMX Maximum, Real Power
b
30, 32, 34 KQ3PMX Maximum, Reactive Power
b
30, 32, 34 IxXMX Maximum, Current Magnitude X (x = A, B, C and G)
c
30, 32, 34 3I2XMX Maximum, Current, Negative Sequence X
c
30, 32, 34 KS3PXMX Maximum, Apparent Power X
c
30, 32, 34 KW3PXMX Maximum, Real Power X
c
30, 32, 34 KQ3PXMX Maximum, Reactive Power X
c
Tab l e D.6 DN P3 Refe r e nc e D ata M ap
a
(Sheet 2 of 3)
Object Labels Description
