7.20
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Communications
ASCII Commands
To view instantaneous metering values, use the MET F k command, where F is
an optional parameter to specify fundamental and k is an optional parameter to
specify the number of times (1–32767) to repeat the meter display. The device
displays the meter report once if k is not specified.
MET Demand/Peak Demand Metering
Use the following commands to view or reset demand and peak demand metering
values.
The MET D command displays the demand and peak demand values of the fol-
lowing quantities along with the last reset times:
➤ Currents
➤ Power
MET M Maximum/Minimum Metering
Use the following commands to view or reset maximum or minimum metering
values.
The MET M command displays the maximum and minimum values of the fol-
lowing quantities along with the last reset times:
➤ Currents
➤ Voltages
➤ Power
For more information on device maximum/minimum metering quantity
calculations, see Maximum and Minimum Metering on page 5.5.
MET E Energy Metering
Use the following commands to view or reset energy metering values.
For more information on device energy metering quantity calculations, see
Energy Metering on page 5.5.
Command Description Access Level
MET D Display demand and peak demand metering data. 1
MET RD Reset demand metering data. 1
MET RP Reset peak demand metering data. 1
Command Description Access Level
MET M Display maximum and minimum metering data. 1
MET RM Reset maximum and minimum metering data. All
values will display RESET until new maximum/
minimum values are recorded.
1
Command Description Access Level
MET E Display energy metering data. 1
MET RE Reset energy metering data. 1
