Analyzing Events
Event Reporting
Filtered and Unfiltered Event Reports
The SEL-2414 provides both filtered and unfiltered (raw) event reports, either at
16 (raw) samples per cycle or 4 samples (filtered) per cycle.
Both raw and filtered event reports show values when optional currents and/or
voltages are installed. These current and/or voltage values are the same as those
described in Table 9.2. For the 16-samples-per-cycle filtered event reports, the
digital outputs are repeated for four 1/16-cycle rows to make up the 1/4-cycle
information.
Column Definitions
To optimize data reporting, the event report generally provides only one place-
holder for more than one digital variable. For example, there is only one “dot” in
the event report for both output contact OUT101 and output contact OUT102. To
indicate device operation, the placeholder displays one of the following (applica-
ble to all input and output cards):
➤ 1—only output contact OUT101 asserted
➤ 2—only output contact OUT102 asserted
➤ b—both output contact OUT101 and output contact OUT102
asserted
Table 9.3 shows the digital column definitions for the base unit (100) and the
optional I/O boards (300 through 600).
Table 9.3 Digital Column Definitions (Sheet 1 of 3)
Column Designation Column Symbols Description
100
OUT 12
1
2
b
OUT101
OUT102
Both
100
OUT 3
3 OUT103
100
IN 12
1
2
b
IN101
IN102
Both
300
IN 12
1
2
b
IN301
IN302
Both
300
IN 34
3
4
b
IN303
IN304
Both
300
IN 56
5
6
b
IN305
IN306
Both
300
IN 78
7
8
b
IN307
IN308
Both
400
IN 12
1
2
b
IN401
IN402
Both
400
IN 34
3
4
b
IN403
IN404
Both
