G.3
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
MIRRORED BITS Communications
Overview
Table G.3 shows an example of the values of the MIRRORED BITS for a RXDFLT
setting of 10100111.
Individual pickup and dropout security counters supervise the movement of each
received data bit into the corresponding RMBn element. You can set each pickup/
dropout security counter from 1 to 8. A setting of 1 causes a security counter to
pass every occurrence, while a setting of 8 causes a counter to wait for eight con-
secutive occurrences in the received data before updating the data bits. The
pickup and dropout security count settings are separate. Control the security
count settings with the settings RMBnPU and RMBnDO.
A pickup/dropout security counter operates identically to a pickup/dropout timer,
except that the counter uses units of counted received messages instead of time.
Select a setting for the security counter in accordance with the transmission rate
(see Table G.1). For example, when transmitting at 2400 baud, a security counter
set to 2 counts delays a bit by about 30 ms. However, when operating at 9600
baud, a setting of 2 counts delays a bit by about 8.5 ms.
You must consider the impact of the security counter settings in the receiving
device to determine the channel timing performance, particularly when two
devices of different processing rates are communicating via M
IRRORED BITS,
such as an SEL-321 and an SEL-2414. The SEL-321 processes power system
information each 1/8 power system cycle, but, when transmitting at 19200 baud,
the SEL-2414 processes M
IRRORED BITS messages at 4.15 ms at 60 Hz (4 times
per power system cycle at 60 Hz). Although the SEL-321 processes power sys-
tem information each 1/8 power system cycle, the device processes the M
IR-
RORED BITS pickup/dropout security counters as MIRRORED BITS messages are
received. Because the SEL-2414 transmits messages at approximately 1/4-cycle
processing interval (9600 baud and above, see Table G.1), a counter set to two in
the SEL-321 delays a received bit by another approximately 1/2 cycle. However,
a security counter in the SEL-2414 with a setting of two delays a received bit
from the SEL-321 by 1/4 cycle, because the SEL-2414 is receiving new M
IR-
RORED BITS messages each 1/8 cycle from the SEL-321.
Channel Synchronization
When an SEL-2414 detects a communications error, it deasserts ROKA or
ROKB. If an SEL-2414 detects two consecutive communications errors, it trans-
mits an attention message, which includes the TXID setting. The device transmits
an attention message until it receives an attention message that includes a match
to the TXID setting value. If the attention message is successful, the device has
properly synchronized and data transmission resumes. If the attention message is
not successful, the device repeats the attention message until it is successful.
Table G.2 Positions of the MIRRORED BITS
Bit/
Row
7 6 5 4 3 2 1 0
97
RMB8A RMB7A RMB6A RMB5A RMB4A RMB3A RMB2A RMB1A
99
RMB8B RMB7B RMB6B RMB5B RMB4B RMB3B RMB2B RMB1B
Tab l e G . 3 MIRRORED BITS Values for a RXDFLT Setting of 10100111
Bit/
Row
7 6 5 4 3 2 1 0
97
10100111
