Sel 2414 - Definitions

H.4
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Device Word Bits
Definitions
Definitions
114
VB081 VB082 VB083 VB084 VB085 VB086 VB087 VB088
115
VB089 VB090 VB091 VB092 VB093 VB094 VB095 VB096
116
VB097 VB098 VB099 VB100 VB101 VB102 VB103 VB104
117
VB105 VB106 VB107 VB108 VB109 VB110 VB111 VB112
118
VB113 VB114 VB115 VB116 VB117 VB118 VB119 VB120
119
VB121 VB122 VB123 VB124 VB125 VB126 VB127 VB128
120
PB01BLED PB02BLED PB03BLEDPB04BLED* * * *
121
* * * * * * * *
122
********
123
* * * AMB_F T1OIL_F T2OIL_F T3OIL_F ETHRFLT
124
TO1_1 TO2_1 TO3_1 TO1 TO1_2 TO2_2 TO3_2 TO2
125
HS1_1 HS2_1 HS3_1 HS1 HS1_2 HS2_2 HS3_2 HS2
126
FAA1_1 FAA2_1 FAA3_1 FAA1 FAA1_2 FAA2_2 FAA3_2 FAA2
127
RLL_1 RLL_2 RLL_3 RLL TLL_1 TLL_2 TLL_3 TLL
128
CSE_1 CSE_2 CSE_3 CSE CSCM_1 CSCM_2 CSCM_3 CSCM
129
CSALARM MAMB_OK MTO1_OK MTO2_OK MTO3_OK TFLTALA TFLTALB TFLTALC
130
TRDE T1CS2 T1CS3 T2CS2 T2CS3 T3CS2 T3CS3 T1_LVL1
131
T1_LVL2 T1_LVL3 T2_LVL1 T2_LVL2 T2_LVL3 T3_LVL1 T3_LVL2 T3_LVL3
132
T1_TO1 W1_TO1 W2_TO1 W3_TO1 T1_TO2 W1_TO2 W2_TO2 W3_TO2
133
T1_HS1 W1_HS1 W2_HS1 W3_HS1 T1_HS2 W1_HS2 W2_HS2 W3_HS2
134
T1_FAA1 W1_FAA1 W2_FAA1 W3_FAA1 T1_FAA2 W1_FAA2 W2_FAA2 W3_FAA2
135
T1_RLL W1_RLL W2_RLL W3_RLL T1_TLL W1_TLL W2_TLL W3_TLL
136
T1_CSCM W1_CSCM W2_CSCM W3_CSCM T1_CSE W1_CSE W2_CSE W3_CSE
137
W1_LVL1 W1_LVL2 W1_LVL3 * W2_LVL1 W2_LVL2 W2_LVL3 *
138
W3_LVL1 W3_LVL2 W3_LVL3 * * * * *
139
* * * * * * * *
140
********
a
IRTDFLT also applies to internal general purpose RTD/TC card.
Table H.1 SEL-2414 Device Word Bits (Sheet 4 of 4)
Bit/
Row
Device Word Bits
7 6 5 4 3 2 1 0
Table H.2 Device Word Bit Definitions (Sheet 1 of 7)
Row Bit Definition
0 ENABLED Device Enabled
T00_LED–
T06_LED
SEL
OGIC Equation: Drives LED 2–LED 8
1PB01_LED–
PB04_LED
SEL
OGIC Equation: Drives Upper Pushbutton LEDs
* Reserved
SALARM Software Alarms: invalid password, changing access levels, settings changes
IRIGOK IRIG-B Time Synchronism-Check Input Data are valid
HALARM Diagnostics Failure
2 RB01–RB08 Remote Bits RB01–RB08
3 RB09–RB16 Remote Bits RB09–RB16
4 RB17–RB24 Remote Bits RB17–RB24
