Device Word Bits
Definitions
5 RB25–RB32 Remote Bits RB25–RB32
6 LB01–LB08 Local Bits LB01–LB08
7 LB09–LB16 Local Bits LB09–LB16
8 LB17–LB24 Local Bits LB17–LB24
9 LB25–LB32 Local Bits LB25–LB32
10 SV01–SV08 SEL
OGIC control equation variables SV01–SV08
11 SV01T–SV08T SEL
OGIC control equation variables SV01T–SV08T with settable pickup and dropout time delay
12 SV09–SV16 SEL
OGIC control equation variables SV09–SV16
13 SV09T–SV16T SEL
OGIC control equation variables SV09T–SV16T with settable pickup and dropout time delay
14 SV17–SV24 SEL
OGIC control equation variables SV17–SV24
15 SV17T–SV24T SEL
OGIC control equation variables SV17T–SV24T with settable pickup and dropout time delay
16 SV25–SV32 SEL
OGIC control equation variables SV25–SV32
17 SV25T–SV32T SEL
OGIC control equation variables SV25T–SV32T with settable pickup and dropout time delay
18 SV33–SV40 SEL
OGIC control equation variables SV33–SV40
19 SV33T–SV40T SEL
OGIC control equation variables SV33T–SV40T with settable pickup and dropout time delay
20 SV41–SV48 SEL
OGIC control equation variables SV41–SV48
21 SV41T–SV48T SEL
OGIC control equation variables SV41T–SV48T with settable pickup and dropout time delay
22 SV49–SV56 SEL
OGIC control equation variables SV49–SV56
23 SV49T–SV56T SEL
OGIC control equation variables SV49T–SV56T with settable pickup and dropout time delay
24 SV57–SV64 SEL
OGIC control equation variables SV57–SV64
25 SV57T–SV64T SEL
OGIC control equation variables SV57T–SV64T with settable pickup and dropout time delay
26 SET01–SET08 SEL
OGIC Set latch bit variables SET01–SET08
27 RST01–RST08 SEL
OGIC Reset latch bit variables RST01–RST08
28 SET09–SET16 SEL
OGIC Set latch bit variables SET09–SET16
29 RST09–RST16 SEL
OGIC Reset latch bit variables RST09–RST16
30 SET17–SET24 SEL
OGIC Set latch bit variables SET17–SET24
31 RST17–RST24 SEL
OGIC Reset latch bit variables RST17–RST24
32 SET25–SET32 SEL
OGIC Set latch bit variables SET25–SET32
33 RST25–RST32 SEL
OGIC Reset latch bit variables RST25–RST32
34 LT01–LT08 Latch bit variables LT01–LT08
35 LT09–LT16 Latch bit variables LT09–LT16
36 LT17–LT24 Latch bit variables LT17–LT24
37 LT25–LT32 Latch bit variables LT25–LT32
38 SC01QU–
SC08QU
SEL
OGIC Counters 01–08 asserted when counter = preset value
39 SC01QD–
SC08QD
SEL
OGIC Counters 01–08 asserted when counter = 0
40 SC09QU–
SC16QU
SEL
OGIC Counters 09–16 asserted when counter = preset value
41 SC09QD–
SC16QD
SEL
OGIC Counters 09–16 asserted when counter = 0
42 SC17QU–
SC24QU
SEL
OGIC Counters 17–24 asserted when counter = preset value
43 SC17QD–
SC24QD
SEL
OGIC Counters 17–24 asserted when counter = 0
44 SC25QU–
SC32QU
SEL
OGIC Counters 25–32 asserted when counter = preset value
45 SC25QD–
SC32QD
SEL
OGIC Counters 25–32 asserted when counter = 0
Table H.2 Device Word Bit Definitions (Sheet 2 of 7)
Row Bit Definition
