Sel 2414 - Page 335

H.3
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Device Word Bits
Overview
67
AI401LW1 AI401LW2 AI401LAL * AI401HW1 AI401HW2 AI401HAL *
68
AI402LW1 AI402LW2 AI402LAL * AI402HW1 AI402HW2 AI402HAL *
69
AI403LW1 AI403LW2 AI403LAL * AI403HW1 AI403HW2 AI403HAL *
70
AI404LW1 AI404LW2 AI404LAL * AI404HW1 AI404HW2 AI404HAL *
71
AI405LW1 AI405LW2 AI405LAL * AI405HW1 AI405HW2 AI405HAL *
72
AI406LW1 AI406LW2 AI406LAL * AI406HW1 AI406HW2 AI406HAL *
73
AI407LW1 AI407LW2 AI407LAL * AI407HW1 AI407HW2 AI407HAL *
74
AI408LW1 AI408LW2 AI408LAL * AI408HW1 AI408HW2 AI408HAL *
75
AI501LW1 AI501LW2 AI501LAL * AI501HW1 AI501HW2 AI501HAL *
76
AI502LW1 AI502LW2 AI502LAL * AI502HW1 AI502HW2 AI502HAL *
77
AI503LW1 AI503LW2 AI503LAL * AI503HW1 AI503HW2 AI503HAL *
78
AI504LW1 AI504LW2 AI504LAL * AI504HW1 AI504HW2 AI504HAL *
79
AI505LW1 AI505LW2 AI505LAL * AI505HW1 AI505HW2 AI505HAL *
80
AI506LW1 AI506LW2 AI506LAL * AI506HW1 AI506HW2 AI506HAL *
81
AI507LW1 AI507LW2 AI507LAL * AI507HW1 AI507HW2 AI507HAL *
82
AI508LW1 AI508LW2 AI508LAL * AI508HW1 AI508HW2 AI508HAL *
83
AI601LW1 AI601LW2 AI601LAL * AI601HW1 AI601HW2 AI601HAL *
84
AI602LW1 AI602LW2 AI602LAL * AI602HW1 AI602HW2 AI602HAL *
85
AI603LW1 AI603LW2 AI603LAL * AI603HW1 AI603HW2 AI603HAL *
86
AI604LW1 AI604LW2 AI604LAL * AI604HW1 AI604HW2 AI604HAL *
87
AI605LW1 AI605LW2 AI605LAL * AI605HW1 AI605HW2 AI605HAL *
88
AI606LW1 AI606LW2 AI606LAL * AI606HW1 AI606HW2 AI606HAL *
89
AI607LW1 AI607LW2 AI607LAL * AI607HW1 AI607HW2 AI607HAL *
90
AI608LW1 AI608LW2 AI608LAL * AI608HW1 AI608HW2 AI608HAL *
91
* * * * * * * *
92
IN101E IN102E * * * * * *
93
IN301E IN302E IN303E IN304E IN305E IN306E IN307E IN308E
94
IN401E IN402E IN403E IN404E IN405E IN406E IN407E IN408E
95
IN501E IN502E IN503E IN504E IN505E IN506E IN507E IN508E
96
IN601E IN602E IN603E IN604E IN605E IN606E IN607E IN608E
97
RMB8A RMB7A RMB6A RMB5A RMB4A RMB3A RMB2A RMB1A
98
TMB8A TMB7A TMB6A TMB5A TMB4A TMB3A TMB2A TMB1A
99
RMB8B RMB7B RMB6B RMB5B RMB4B RMB3B RMB2B RMB1B
100
TMB8B TMB7B TMB6B TMB5B TMB4B TMB3B TMB2B TMB1B
101
LBOKB CBADB RBADB ROKB LBOKA CBADA RBADA ROKA
102
PB01 PB02 PB03 PB04 * * * *
103
PB01_PUL PB02_PUL PB03_PUL PB04_PUL * * * *
104
VB001 VB002 VB003 VB004 VB005 VB006 VB007 VB008
105
VB009 VB010 VB011 VB012 VB013 VB014 VB015 VB016
106
VB017 VB018 VB019 VB020 VB021 VB022 VB023 VB024
107
VB025 VB026 VB027 VB028 VB029 VB030 VB031 VB032
108
VB033 VB034 VB035 VB036 VB037 VB038 VB039 VB040
109
VB041 VB042 VB043 VB044 VB045 VB046 VB047 VB048
110
VB049 VB050 VB051 VB052 VB053 VB054 VB055 VB056
111
VB057 VB058 VB059 VB060 VB061 VB062 VB063 VB064
112
VB065 VB066 VB067 VB068 VB069 VB070 VB071 VB072
113
VB073 VB074 VB075 VB076 VB077 VB078 VB079 VB080
Table H.1 SEL-2414 Device Word Bits (Sheet 3 of 4)
Bit/
Row
Device Word Bits
7 6 5 4 3 2 1 0
