SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Device Word Bits
Overview
20
SV41 SV42 SV43 SV44 SV45 SV46 SV47 SV48
21
SV41T SV42T SV43T SV44T SV45T SV46T SV47T SV48T
22
SV49 SV50 SV51 SV52 SV53 SV54 SV55 SV56
23
SV49T SV50T SV51T SV52T SV53T SV54T SV55T SV56T
24
SV57 SV58 SV59 SV60 SV61 SV62 SV63 SV64
25
SV57T SV58T SV59T SV60T SV61T SV62T SV63T SV64T
26
SET01 SET02 SET03 SET04 SET05 SET06 SET07 SET08
27
RST01 RTS02 RST03 RST04 RST05 RST06 RST07 RST08
28
SET09 SET10 SET11 SET12 SET13 SET14 SET15 SET16
29
RST09 RST10 RST11 RST12 RST13 RST14 RST15 RST16
30
SET17 SET18 SET19 SET20 SET21 SET22 SET23 SET24
31
RST17 RST18 RST19 RST20 RST21 RST22 RST23 RST24
32
SET25 SET26 SET27 SET28 SET29 SET30 SET31 SET32
33
RST25 RST26 RST27 RST28 RST29 RST30 RST31 RST32
34
LT01 LT02 LT03 LT04 LT05 LT06 LT07 LT08
35
LT09 LT10 LT11 LT12 LT13 LT14 LT15 LT16
36
LT17 LT18 LT19 LT20 LT21 LT22 LT23 LT24
37
LT25 LT26 LT27 LT28 LT29 LT30 LT31 LT32
38
SC01QU SC02QU SC03QU SC04QU SC05QU SC06QU SC07QU SC08QU
39
SC01QD SC02QD SC03QD SC04QD SC05QD SC06QD SC07QD SC08QD
40
SC09QU SC10QU SC11QU SC12QU SC13QU SC14QU SC15QU SC16QU
41
SC09QD SC10QD SC11QD SC12QD SC13QD SC14QD SC15QD SC16QD
42
SC17QU SC18QU SC19QU SC20QU SC21QU SC22QU SC23QU SC24QU
43
SC17QD SC18QD SC19QD SC20QD SC21QD SC22QD SC23QD SC24QD
44
SC25QU SC26QU SC27QU SC28QU SC29QU SC30QU SC31QU SC32QU
45
SC25QD SC26QD SC27QD SC28QD SC29QD SC30QD SC31QD SC32QD
46
* DSABLSET RSTTRGT ER TRGTR SPEN * *
47
RELAY_EN * * * MATHERR ERTDIN ERTDFLT IRTDFLT
a
48
IN101 IN102 * * * * * *
49
IN301 IN302 IN303 IN304 IN305 IN306 IN307 IN308
50
IN401 IN402 IN403 IN404 IN405 IN406 IN407 IN408
51
IN501 IN502 IN503 IN504 IN505 IN506 IN507 IN508
52
IN601 IN602 IN603 IN604 IN605 IN606 IN607 IN608
53
OUT101 OUT102 OUT103 * * * * *
54
OUT301 OUT302 OUT303 OUT304 OUT305 OUT306 OUT307 OUT308
55
OUT401 OUT402 OUT403 OUT404 OUT405 OUT406 OUT407 OUT408
56
OUT501 OUT502 OUT503 OUT504 OUT505 OUT506 OUT507 OUT508
57
OUT601 OUT602 OUT603 OUT604 OUT605 OUT606 OUT607 OUT608
58
AILW1 AILW2 AILAL * AIHW1 AIHW2 AIHAL *
59
AI301LW1 AI301LW2 AI301LAL * AI301HW1 AI301HW2 AI301HAL *
60
AI302LW1 AI302LW2 AI302LAL * AI302HW1 AI302HW2 AI302HAL *
61
AI303LW1 AI303LW2 AI303LAL * AI303HW1 AI303HW2 AI303HAL *
62
AI304LW1 AI304LW2 AI304LAL * AI304HW1 AI304HW2 AI304HAL *
63
AI305LW1 AI305LW2 AI305LAL * AI305HW1 AI305HW2 AI305HAL *
64
AI306LW1 AI306LW2 AI306LAL * AI306HW1 AI306HW2 AI306HAL *
65
AI307LW1 AI307LW2 AI307LAL * AI307HW1 AI307HW2 AI307HAL *
66
AI308LW1 AI308LW2 AI308LAL * AI308HW1 AI308HW2 AI308HAL *
Table H.1 SEL-2414 Device Word Bits (Sheet 2 of 4)
Bit/
Row
Device Word Bits
7 6 5 4 3 2 1 0
